• OMNICONVERTER 10G/M AC EXT TEMP
    OMNICONVERTER 10G/M AC EXT TEMP
1 1

Omnitron Systems OmniConverter 10G/M 2xSFP/SFP+ 8xRJ-45 1xAC Powered Extended Temp

Omnitron Systems OmniConverter 10G/M 2xSFP/SFP+ 8xRJ-45 1xAC Powered Extended Temp

SKU: 1065692929      MFR: Omnitron Systems

GTIN: 800975042094

Product Description

Omnitron Systems OmniConverter 10G/M 2xSFP/SFP+ 8xRJ-45 1xAC Powered Extended Temp - 10 Ports - Manageable - 2 Layer Supported - Modular - Optical Fiber Twisted Pair - Wall Mountable DIN Rail Mountable Shelf Mountable Rack-mountable - 5 Year Limited Warranty

Manufacturer : Omnitron Systems

Manufacturer Part No : 2900-0-28-1Z

Features

  • Expand your network capacity with the help of 10 networking ports and transfer your data quickly and easily
  • Cascade to other network devices through the uplink port to expand your local area network
  • Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
  • Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
  • Layer 2 switch provides a complete lineup of features including IGMP snooping port mirroring and spanning tree
  • Managed switch provides a reliable foundation for your network
  • No need to deal with power supply issues the switch comes with a separate AC adapter to power up the unit
  • With Wall mounting feature you can conveniently install the switch while keeping the wires and cables organized

Product Details

Product TypeEthernet Switch
ManageableYes
Environmentally FriendlyYes
Environmental CertificationREACH
Ethernet TechnologyGigabit Ethernet
Number of Total Expansion Slots2
Number of SFP+ Slots2
ModularYes
Management PortYes
Uplink PortYes
Media Type SupportedOptical Fiber
Total Number of Network Ports10
Port/Expansion Slot Details8 x Gigabit Ethernet Network
Country of OriginUnited States
Height1.5"
Width6.3"
Depth5.2"
Expansion Slot TypeSFP+
Certifications & Standards
  • IEEE 802.3
  • IEEE 802.3ae
  • IEEE 802.1Q
  • IEEE 802.1ad
  • IEEE 802.1ab
  • IEEE 802.1w
  • IEEE 802.1ax
  • RFC 5424
  • RFC 4541
  • IEC 624339-2
  • SMTP SNTP
  • RADIUS TACACS+ IEEE 802.1x
Safety:
  • UL 60950-1 UL-62368-1
  • IEC 62368:2014 /A11:2017
  • IEC 60950-1:2005+A1:2009
  • EN 60950-1:2006+A11:2009+A1:2010+A12:2011 +A2:2013
  • CAN/CSA C22.2 No. 60950-1
  • CAN/CSA C22.2 No. 62368-1-14
  • CE Mark
EMC: EN 55032/EN 55024 CE Emissions/Immunity

EMI: CISPR 32 FCC 47 Part 15 Subpart B Class A

EMS:
  • IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
  • IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
  • IEC 61000-4-4 EFT: Power: 1 kV; Signal:0.5 kV
  • IEC 61000-4-5 Surge: Power: 1 kV; Signal: 1 kV
  • IEC 61000-4-6 CS: Signal: 3 V
  • IEC 61000-4-8 ( Magnetic Field)
  • IEC 61000-4-11
IP Rating: IP20 Protection
Product Series10G/M
Brand NameOmnitron Systems
Plug/Connector TypeBarrel
Form FactorWall Mountable
ManufacturerOmnitron Systems
Product Model2900-0-28-1Z
Product NameOmniConverter 10G/M 2xSFP/SFP+ 8xRJ-45 1xAC Powered Extended Temp
Network Technology10/100/1000Base-T
Package TypeRetail
Product LineOmniConverter
Input Voltage120 V AC
Input Voltage230 V AC
Manufacturer Part Number2900-0-28-1Z
Manufacturer Website Addresshttp://www.omnitron-systems.com
Marketing InformationThe OmniConverter 10G/M is a managed compact Ethernet switch that features two 1/10G uplink ports and four or eight 10/100/1000 RJ-45 copper user ports. The OmniConverter 10G/M enables network distance extension with fiber cabling.

The OmniConverter 10G/M is a Layer 2 Ethernet switch that forwards frames to any port based on their MAC address.

The OmniConverter 10G/M supports Directed Switch mode which directs multicast traffic (such as video) only to the appropriate uplink port preventing the multicast video traffic from flooding other network ports.

The switches support redundant uplinks industrial ring Media Redundancy Protocol (MRP) Spanning Tree protocol and daisy-chain configurations for high availability industrial network applications.

The switches support Dual Device mode that enables the 10G/M to operate as two independent and isolated Ethernet switches. In Dual Device mode the 10G/M provides separate and independent data traffic paths between each uplink port and a group of user ports.

The mode of operation can be configured using easily accessible DIP-switches or using Web Telnet SSH SNMPv1/v2c/v3 or Serial Console management interfaces. These management interfaces provide access to filtering and security options such as broadcast storm prevention IGMP IEEE 802.1x RADIUS TACACS+ and Access Control Lists. Email event notification and alarm reporting is provided using Simple Mail Transfer Protocol.

The OmniConverter switches are available with Small Form Pluggable (SFP) transceiver receptacle ports. The SFP ports support 10/100/1000BASE-T 1000BASE-T and 10GBASE-T copper transceivers. They also support 1G and 10G multimode or single-mode fiber dual or single-fiber and standard or CWDM wavelengths.

The compact OmniConverter 10G/M Ethernet switches can be wall mounted rack mounted using a shelf or DIN-rail mounted using DIN-rail mounting clips. The OmniConverter Ethernet switch models are available with 2-Pin DC Terminal or external 100-240V AC power adapters.
Packaged Quantity1
Power SourceAC Adapter
Package Contents
  • OmniConverter 10G/M 2xSFP/SFP+ 8xRJ-45 1xAC Powered Extended Temp
  • User Manual
Limited Warranty5 Year
Layer Supported2
Additional InformationManagement Port: 1

Number of Serial Ports: 1

Management: Web Telnet SSH Serial Console SNMPv1/v2/v3

Input Voltage:
  • 0.25A max at 115VAC
  • 0.12A max at 230VAC
Operating Temperature Range: -40 to +75 deg C"
Weight (Approximate)1.60 lb
Product FamilyOmniConverter 10G/M
View full details
$2,116.99 USD
$2,116.99
Sale Sold out

Back Order

Get it by Mon, Jan 26 - Sat, Jan 31


Update


Shipping calculated at checkout.

Omnitron Systems OmniConverter 10G/M 2xSFP/SFP+ 8xRJ-45 1xAC Powered Extended Temp - 10 Ports - Manageable - 2 Layer Supported - Modular - Optical Fiber Twisted Pair - Wall Mountable DIN Rail Mountable Shelf Mountable Rack-mountable - 5 Year Limited Warranty
