Advantech EKI-2525S Ethernet Switch

Advantech EKI-2525S Ethernet Switch

SKU: 1041315252      MFR: Advantech Co. Ltd

Product Description

Advantech EKI-2525S Ethernet Switch - 4 Ports - 2 Layer Supported - Twisted Pair Optical Fiber - Wall Mountable DIN Rail Mountable - 5 Year Limited Warranty

Manufacturer : Advantech Co. Ltd

Manufacturer Part No : EKI-2525S-BE

Features

  • Provides 4 x 10/100 Mbps Ethernet ports with RJ45 connector
  • Provides 1 x 100 Mbps Multi-mode SC type fiber optic port (EKI-2525M)
  • Provides 1 x 100 Mbps Multi-mode ST type fiber optic port (EKI-2525M-ST)
  • Provides 1 x 100 Mbps Single-mode SC type fiber optic port (EKI-2525S)
  • Supports full/half duplex flow control
  • Supports MDI/MDI-X auto crossover
  • Provides broadcast storm protection
  • Provides redundant 12 ~ 48 VDC power input
  • Provides flexible mounting: DIN-rail and Wall mount

Product Details

Total Number of Network Ports4
Port/Expansion Slot Details5 x Fast Ethernet Network
Height5.5"
Width1.2"
Depth3.7"
Product SeriesEKI-2000
Brand NameAdvantech
Form FactorWall Mountable
ManufacturerAdvantech Co. Ltd
Product ModelEKI-2525S
Product NameEKI-2525S Ethernet Switch
Network Technology10/100Base-TX
Manufacturer Part NumberEKI-2525S-BE
Manufacturer Website Addresshttp://www.advantech.com
Marketing InformationEKI-2525M/2525S are industrial-grade Ethernet switches that enable you to expand your industrial network fast and cost-effectively. The EKI-2525M/2525S have four 10/100 Mbps Ethernet ports and additionally the EKI-2525M provides one multi-mode fiber-optic ports while the EKI-2525S provide one single-mode fiber-optic ports. Using fiber-optics you can prevent noise from interfering with your system and supports high-speed (100 Mbps) and high-distance (up to 30 km) transmissions.

EKI-2525M/2525S have industrial-grade designs assuring high reliability and stability in harsh environments making it a robust bridge between enterprise fiber-optic backbones and Ethernet devices. EKI-2525M/2525S includes a switch controller that can automatically sense transmission speeds. The RJ45 interface can also be autodetected so MDI or MDI-X is automatically selected and a crossover cable is not required. All the Ethernet ports have memory buffers that support the store and forward mechanism assuring all data is transmitted properly.
Limited Warranty5 Year
Layer Supported2
Product TypeEthernet Switch
ManageableNo
Ethernet TechnologyFast Ethernet
Product FamilyEKI-2000
Stack PortNo
Media Type SupportedTwisted Pair
Environmentally FriendlyYes
Environmental CertificationRoHS
ModularNo
Uplink PortNo
View full details
$219.99 USD
$219.99
Sale Sold out

Back Order

Get it by Tue, Aug 04 - Sun, Aug 09


Update


Shipping calculated at checkout.
