• Areca PCIe 2.0 6Gb/s SATA RAID Controller
    Areca PCIe 2.0 6Gb/s SATA RAID Controller
1 1

Areca PCIe 2.0 6Gb/s SATA RAID Controller

Areca PCIe 2.0 6Gb/s SATA RAID Controller

SKU: 1025811252      MFR: Areca Technology Corp.

GTIN: 4712774411253

Product Description

Areca PCIe 2.0 6Gb/s SATA RAID Controller - Serial ATA/600 - PCI Express 2.0 x8 - Plug-in Card - RAID Supported - 0 1 1E 3 5 6 10 30 50 60 JBOD RAID Level - 16 Total SATA Port(s) - Linux PC Mac - 1 GB NV Cache

Manufacturer : Areca Technology Corp.

Manufacturer Part No : ARC-1264IL-16

Product Details

Platform SupportedLinux
Host InterfacePCI Express 2.0 x8
Product TypeSATA Controller
RAID SupportedYes
Data Backup TypeNV Cache
Total Number of SATA Ports16
SATA Connector Details4 x Multilane
Brand NameAreca
Form FactorPlug-in Card
RAID Levels0
Controller TypeSerial ATA/600
Environmentally FriendlyYes
Environmental CertificationRoHS
Cache Memory1 GB
Height2.5"
Depth8"
ManufacturerAreca Technology Corp.
Product ModelARC-1264IL-16
Product NamePCIe 2.0 6Gb/s SATA RAID Controller
Manufacturer Part NumberARC-1264IL-16
Manufacturer Website Addresshttp://www.areca.us
Marketing InformationARC-1264il-12/16 and ARC-1284Ml-24 RAID controllers are a cost-effective RAID storage solution that combines low-cost SATA III and port multiplier chips with low latency for internal storage systems. It is aimed at high-availability and capacity oriented applications more than 8 HDDs such as security systems surveillance multimedia content generation large-volume data capturing mail servers and entry-level database systems. Its performance is limited by the port multiplier chip numbers on the controller. Applications will get the best performance when you attach the max number HDDs on the RAID controller or rearrange the HDD position to use max port multiplier chip. Each SFF-8087 connector uses one port multiplier chip. ARC-1264il-12/16 and ARC-1284Ml-24 internal PCIe 2.0 host RAID controllers are based on the same RAID kernel of field-proven internal/external RAID controller and same device driver architecture with widely used 3Gb/s and 6Gb/s SAS/SATA RAID controller. They can support directly attached 12/16/24 internal 6Gb/s SATA ports via 3/4/6 SFF-8087 connectors.

The ML version comes with Min SAS 4i internal connector. This Min SAS 4i (SFF-8087) connector has eight signal pins to support four SATA drives and six pins for the SGPIO (Serial General Purpose Input/Output) side-band signals. The SGPIO bus is for efficient LED management and for sensing drive locate status without any discrete fault & activity cable needed.
View full details
$960.99 USD
$960.99
Sale Sold out

Back Order

Get it by Fri, Dec 04 - Wed, Dec 09


Update


Shipping calculated at checkout.

Areca PCIe 2.0 6Gb/s SATA RAID Controller - Serial ATA/600 - PCI Express 2.0 x8 - Plug-in Card - RAID Supported - 0 1 1E 3 5 6 10 30 50 60 JBOD RAID Level - 16 Total SATA Port(s) - Linux PC Mac - 1 GB NV Cache

Manufacturer : Areca Technology Corp.

Manufacturer Part No : ARC-1264IL-16

Product Details

Platform SupportedLinux
Host InterfacePCI Express 2.0 x8
Product TypeSATA Controller
RAID SupportedYes
Data Backup TypeNV Cache
Total Number of SATA Ports16
SATA Connector Details4 x Multilane
Brand NameAreca
Form FactorPlug-in Card
RAID Levels0
Controller TypeSerial ATA/600
Environmentally FriendlyYes
Environmental CertificationRoHS
Cache Memory1 GB
Height2.5"
Depth8"
ManufacturerAreca Technology Corp.
Product ModelARC-1264IL-16
Product NamePCIe 2.0 6Gb/s SATA RAID Controller
Manufacturer Part NumberARC-1264IL-16
Manufacturer Website Addresshttp://www.areca.us
Marketing InformationARC-1264il-12/16 and ARC-1284Ml-24 RAID controllers are a cost-effective RAID storage solution that combines low-cost SATA III and port multiplier chips with low latency for internal storage systems. It is aimed at high-availability and capacity oriented applications more than 8 HDDs such as security systems surveillance multimedia content generation large-volume data capturing mail servers and entry-level database systems. Its performance is limited by the port multiplier chip numbers on the controller. Applications will get the best performance when you attach the max number HDDs on the RAID controller or rearrange the HDD position to use max port multiplier chip. Each SFF-8087 connector uses one port multiplier chip. ARC-1264il-12/16 and ARC-1284Ml-24 internal PCIe 2.0 host RAID controllers are based on the same RAID kernel of field-proven internal/external RAID controller and same device driver architecture with widely used 3Gb/s and 6Gb/s SAS/SATA RAID controller. They can support directly attached 12/16/24 internal 6Gb/s SATA ports via 3/4/6 SFF-8087 connectors.

The ML version comes with Min SAS 4i internal connector. This Min SAS 4i (SFF-8087) connector has eight signal pins to support four SATA drives and six pins for the SGPIO (Serial General Purpose Input/Output) side-band signals. The SGPIO bus is for efficient LED management and for sensing drive locate status without any discrete fault & activity cable needed.
