ASUSTOR Lockerstor 4 AS6704T SAN/NAS Storage System

ASUSTOR Lockerstor 4 AS6704T SAN/NAS Storage System

SKU: 1073875679      MFR: ASUSTOR

GTIN: 887372901612

Product Description

ASUSTOR Lockerstor 4 AS6704T SAN/NAS Storage System - Intel Celeron N5105 Quad-core (4 Core) 2 GHz - 4 x HDD Supported - 0 x HDD Installed - 4 x SSD Supported - 0 x SSD Installed - 4 GB RAM DDR4 SDRAM - Serial ATA/600 Controller - RAID Supported 0 1 5 6 10 JBOD - 4 x Total Bays - 4 x 2.5"/3.5" Bay - 1 x Total Slot(s) - 2.5 Gigabit Ethernet Gigabit Ethernet Fast Ethernet - HDMI - 2 USB Port(s) - Network (RJ-45) - ADM 4.1 - IMAP IPSec TCP/IP SMTP HTTPS LDAP L2TP SFTP UDP SSH

Manufacturer : ASUSTOR

Manufacturer Part No : AS6704T

Features

  • SAN/NAS Storage System is the single answer to all your desired storage needs
  • Holds up to 4 HDDs
  • Through RAID levels (0 1 5 6 10 jbod) RAID provides data reliability fault tolerance and improves overall performance
  • DDR4 SDRAM memory technology for fast easy and convenient access and retrieval of data and information
  • Experience responsive performance power adaptability and fun with Intel Celeron 2 ghz processor
  • Through RAID levels (0 1 5 6 10 jbod) RAID provides data reliability fault tolerance and improves overall performance
  • Desktop form factor for your convenience and simplicity of usage
  • Gigabit Ethernet is very resourceful when a large number of file transfers are required such as when performing backups over a network
  • ADM 4.1 OS with all the creative and productive tools you need

Product Details

Product TypeSAN/NAS Storage System
Flash Memory Capacity8 GB
Processor ManufacturerIntel
RAID SupportedYes
Ethernet Technology2.5 Gigabit Ethernet
Number of Total Expansion Bays4
Number of Total Expansion Slots1
HDMIYes
Network (RJ-45)Yes
Maximum Power Supply Wattage90 W
Product FamilyLockerstor 4
Total Number of USB Ports2
Number of Hard Drives Supported4
Number of Hard Drives Installed0
Limited Warranty Duration3 Year
Expansion Slot TypePCI Express
Operating SystemADM 4.1
Brand NameASUSTOR
Form FactorDesktop
Processor Speed2 GHz
Processor TypeCeleron
RAID Levels0 1 5 6 10 JBOD
Controller TypeSerial ATA/600
Standard Memory4 GB
Processor CoreQuad-core (4 Core)
Number of Power Supplies Installed1
Number of Network (RJ-45) Ports2
Number of Solid State Drive Supported4
Number of Solid State Drive Installed0
Number of 2.5"/3.5" Bays4
Number of USB 3.2 Gen 2 Ports2
Processor ModelN5105
Height7.3"
Width6.7"
Depth9.1"
Memory TechnologyDDR4 SDRAM
ManufacturerASUSTOR
Product ModelAS6704T
Product NameLockerstor 4 AS6704T SAN/NAS Storage System
Product LineLockerstor 4
Manufacturer Part NumberAS6704T
Manufacturer Website Addresshttp://www.asustor.com
Marketing Information

The No-Compromises 2.5GbE NAS | LOCKERSTOR Gen2 Series

Enthusiast-grade NAS with two four or six bays

The LOCKERSTOR Gen2 series of NAS devices come with the all-new Quad-Core Intel Celeron N5105 CPU featuring Intel 10 nm technology. Intel's Jasper Lake Celeron CPUs bring up to 31% extra performance over the previous generation of Celeron CPUs. The LOCKERSTOR Gen2 is flexible. Install up to four M.2 SSDs or a 10-Gigabit Ethernet card in the available PCI Express slot for maximum performance.
The LOCKERSTOR Gen2 uses DDR4-2933 and super-fast 2.5-Gigabit Ethernet which makes content creation even easier than ever before.

Unleashed Strength

Uses powerful software tools to ensure data is safe and secure

Unleashed Speed

Uses faster hardware for more efficiency

Unleashed Creativity

Maximum creativity without computing constraints

Unleashed Potential

  • Supports Premiere Pro & Final Cut Pro
  • Easily collaborate with anyone anywhere.
  • Adobe Creative Cloud data backup and version control
  • Stream YouTube and/or Twitch videos with rebroadcasting and live recording functionality

CPU

Intel's newest N5105 Quad-Core CPU comes with Intel 10 nm technology and up to 31% increased performance over Gemini Lake SoCs. The N5105 is clocked at 2.0 GHz with a boost of up to 2.9 GHz enabling efficient content creation with the added flexibility of 10-Gigabit Ethernet upgrades.

Keeping Cool

With up to four SSDs a considerable amount of heat can be generated. With extra ventilation the Lockerstor Gen2 ensures that all components in your NAS receive cooling.

USB 3.2 Gen 2x1 - A First for ASUSTOR

The Lockerstor Gen2 series now support USB 3.2 Gen 2x1 for the first time on an ASUSTOR NAS. Enjoy up to double the performance compared with USB 3.2 Gen1 at up to 10 Gbps.

Four M.2 Slots

The Lockerstor Gen2 series of NAS devices come with four M.2 slots for caching or storage or both. Either use all slots for one purpose or mix and match depending on your needs.

Tool-Free M.2 SSD Installation

Uses latches instead of screws for easier installation.

Also Supports 10-Gigabit Ethernet

The PCIe slot in the Lockerstor Gen2 series is no longer proprietary and now accepts 10-Gigabit Ethernet cards for maximum flexibility.

ProtocolsIMAP
Packaged Quantity1
Package Contents
  • Lockerstor 4 AS6704T SAN/NAS Storage System
  • Quick Installation Guide
  • 1 x AC Power Cord
  • 1 x AC Power Adapter
  • 2 x RJ-45 LAN Cable(Cat 5e)
  • 16 x Flat Head Screw (for 3.5" HDD)
  • 16 x Flat Head Screw (for 2.5" HDD)
Limited Warranty3 Year
Weight (Approximate)6.48 lb
