ATEN 4-Port True 4K HDMI Splitter

ATEN 4-Port True 4K HDMI Splitter

SKU: 1040749130      MFR: ATEN Technology Inc

GTIN: 672792007323

Product Description

ATEN 4-Port True 4K HDMI Splitter - 4096 x 2160 - 49.21 ft Maximum Operating Distance - 1 x HDMI In - 4 x HDMI Out - Metal

Manufacturer : ATEN Technology Inc

Manufacturer Part No : VS184B

Features

  • Connects one HDMI source to four HDMI displays at the same time
  • HDMI (3D Deep Color 4K); HDCP 2.2 Compatible
  • Supports HDR
  • Supports max resolutions of up to 4096 x 2160 / 3840 x 2160 @ 60 Hz (4:4:4)
  • Long distance transmission- up to 15 m(1920x1200) / 1.8m (True 4K)*
  • Max pixel clock rate up to 600 MHz
  • Max data rate up to 18 Gbps (6 Gbps per lane)
  • LED indication of power status and source devices
  • EDID Expert™ - Selects optimum EDID settings for smooth power-up high-quality display and use of the best video resolution via EDID DIP Switch allowing users to effortlessly switch among Port 1 Default and Auto
  • Plug-and-play - No software installation required

Product Details

Product TypeSignal Splitter
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Video Resolution4096 x 2160
Maximum Operating Distance49.21 ft
Number of HDMI Inputs1
Number of HDMI Outputs4
HDMI InYes
HDMI OutYes
Country of OriginChina
Height1"
Width3.2"
Brand NameATEN
Length7.9"
ManufacturerATEN Technology Inc
Product ModelVS184B
Product Name4-Port True 4K HDMI Splitter
Input Voltage5 V DC
Manufacturer Part NumberVS184B
Manufacturer Website Addresshttp://www.aten.com/us/en/
Marketing Information

The VS184B True 4K HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMIenabled equipment such as DVD players satellite set- top boxes and all HDMI monitors displays projectors or TVs.

The VS182B True 4K HDMI Splitter is HDMI 2.0 compliant 4K at 60Hz (4:4:4) and supports multiple streaming audio making it effective for use with all HDMI displays in home theater applications as well as in corporate educational and commercial settings.

More from the Manufacturer
Packaged Quantity1
Package Contents
  • 4-Port True 4K HDMI Splitter
  • 1 x Power Adapter
  • 1 x HDMI Cable
  • 1 x User Instructions
MaterialMetal
Weight (Approximate)1.06 lb
