ATEN HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)-TAA Compliant

ATEN HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)-TAA Compliant

SKU: 1048880825      MFR: ATEN Technology Inc

GTIN: 0672792007989

Product Description

ATEN HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)-TAA Compliant - 1 Input Device - 492.13 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable

Manufacturer : ATEN Technology Inc

Manufacturer Part No : VE814AT

Features

  • Extends HDMI signals to one local and two remote displays up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
  • HDMI (3D Deep Color 4K); HDCP 2.2 compatible
  • Superior video quality:
  • 4K up to 100 m
  • 1080p up to 150 m when in HDBaseT Long Reach Mode
  • Extends Ethernet communication using the Ethernet pass-through port
  • Supports two IR channels for simultaneous IR signal transmissions ranged from 30 KHz to 56 KHz
  • ATEN EDID Technology -- when both transmitter and receiver sides are connected VE814A adopts the EDID values of the display connected to the VE814AT for high-quality output
  • RS-232 channel - allows you to connect to serial terminals or serial devices such as touch screens and barcode scanners
  • Supports wide screen format

Product Details

Transmitter Height1.14"
Transmitter Width3.98"
Transmitter Depth5.35"
Transmitter Weight (Approximate)15.87 oz
Country of OriginTaiwan
Connectivity TechnologyWired
Brand NameATEN
Form FactorRack-mountable
ManufacturerATEN Technology Inc
Product ModelVE814AT
Product NameHDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)
Product LineVanCryst
Manufacturer Part NumberVE814AT
Manufacturer Website Addresshttp://www.aten.com/us/en/
Marketing Information

ATEN VE814AT is an HDBaseT Video Transmitter that is capable of sending HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring dual synchronous outputs the VE814AT can transmit video signal to two remote displays and one at the local side. This HDCP 2.2-compliant transmitter meets the HDMI Specification including 3D Deep Color the maximum data rate of (10.2 Gbps) and 4K video quality up to 100 m.

The VE814AT supports RS-232 and IR signaling pass-through allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE8014AT). In addition it supports Long Reach Mode that extends HDMI signals up to 150 m 1080p via a single Cat 5e/6 cable.

The VE814AT is a powerful solution for where digital signage is required such as bars educational spaces and public transportation stations allowing display of identical contents at different spots.
Package Contents
  • HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)
  • 1 x RS-232 Terminal Block
  • 1 x Power Adapter
  • 1 x User Instructions
Product TypeVideo Extender Transmitter
Graphics Modes4K
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Video Resolution4096 x 2160
Twisted Pair Cable StandardCategory 6a
Maximum Operating Distance492.13 ft
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Serial PortYes
Number of HDMI Inputs1
Number of HDMI Outputs1
HDMI InYes
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Input Devices Supported1
Product FamilyVanCryst
