ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)

ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)

SKU: 1063574265      MFR: ATEN Technology Inc

GTIN: 672792011382

Product Description

ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A) - 2 Input Device - 492.13 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 1 x VGA In - 4K UHD - 4096 x 2160 - Twisted Pair - Category 6a - Desktop Rack-mountable

Manufacturer : ATEN Technology Inc

Manufacturer Part No : VE2812AT

Features

  • Extends HDMI or VGA signals providing superior video quality: : HDMI: 4K / 1080p at distance up to 100 m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable : VGA: 1600 x 1200 and 1920 x 1200 up to 100 m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
  • HDMI (3D Deep color 4K); HDCP compatible
  • Supports HDBaseT Long Reach Mode - up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p
  • Built-in PoH (Power over HDBaseT) function - the VE2812AT receives power supply from the HDBaseT output port on the connected device
  • Supports Auto Switch - allows the VE2812AT to automatically switch to a newly plugged-in source
  • Functions as a switch or a converter: : A Switch: Connects two sources (HDMI or VGA) : A converter: Applies receivers with different interface (DVI DisplayPortor HDMI)
  • RS-232 Channel Transmission - allows you to connect to serial terminals or serial devices such as touch screens and barcode scanners
  • Compatible Receivers - VE2812R VE1812R VE811R VE814AR VE801R VE802R VE601R VE901R or future ATEN HDBaseT Receivers
  • Plug-and-play with no software installation required
  • Rack mountable

Product Details

Product TypeVideo Extender Transmitter
Graphics Modes4K UHD
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Video Resolution4096 x 2160
Twisted Pair Cable StandardCategory 6a
Maximum Operating Distance492.13 ft
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Number of HDMI Inputs1
VGA InYes
HDMI InYes
Media Type SupportedTwisted Pair
Number of Input Devices Supported2
Transmitter Height1.18"
Transmitter Width4.84"
Transmitter Depth5.64"
Transmitter Weight (Approximate)1.04 lb
Number of VGA Inputs1
Connectivity TechnologyWired
Brand NameATEN
Form FactorDesktop
ManufacturerATEN Technology Inc
Product ModelVE2812AT
Product NameHDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
Product LineVanCryst
Manufacturer Part NumberVE2812AT
Manufacturer Website Addresshttp://www.aten.com/us/en/
Marketing Information

ATEN VE2812AT is a transmitter for sending VGA (with audio) and HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring built-in PoH (Power over HDBaseT) function the VE2812AT receives power supply from the HDBaseT output port on the connected device. This eliminates the need for a power adapter and reduces the hassle of power line deployment behind the wall. The VE2812AT guarantees reliable transmission of HDMI signals supporting 3D Deep Color and embedded HD lossless audio formats. It also ensures transmission of VGA (with audio) at distance up to 100 m. In addition it supports Long Reach Mode up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p.

For utility flexibility the VE2812AT can serve as a video switch by connecting two sources and distribute them to an identical output. The VE2812AT is recommended to be deployed in paired with the VE2812R. The VE2812R can carry on IR/RS-232 from the VE2812R to the VE2812AT allowing users to remotely control the VE2812AT unit through RS-232 command mode via input port switching. The solution is ideal for a variety of settings such as meeting rooms digital educational environment or wherever high video quality is required.
Package Contents
  • HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
  • 1 x RS-232 Terminal Block
  • 4 x Foot Pads
  • 1 x Power Adapter
  • 1 x User Instructions
Product FamilyVanCryst
View full details
$382.99 USD
$382.99
Sale Sold out

Dropship

Get it by Fri, Dec 13 - Wed, Dec 18


Update


Shipping calculated at checkout.

ATEN HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A) - 2 Input Device - 492.13 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 1 x VGA In - 4K UHD - 4096 x 2160 - Twisted Pair - Category 6a - Desktop Rack-mountable

Manufacturer : ATEN Technology Inc

Manufacturer Part No : VE2812AT

Features

  • Extends HDMI or VGA signals providing superior video quality: : HDMI: 4K / 1080p at distance up to 100 m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable : VGA: 1600 x 1200 and 1920 x 1200 up to 100 m via a Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
  • HDMI (3D Deep color 4K); HDCP compatible
  • Supports HDBaseT Long Reach Mode - up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p
  • Built-in PoH (Power over HDBaseT) function - the VE2812AT receives power supply from the HDBaseT output port on the connected device
  • Supports Auto Switch - allows the VE2812AT to automatically switch to a newly plugged-in source
  • Functions as a switch or a converter: : A Switch: Connects two sources (HDMI or VGA) : A converter: Applies receivers with different interface (DVI DisplayPortor HDMI)
  • RS-232 Channel Transmission - allows you to connect to serial terminals or serial devices such as touch screens and barcode scanners
  • Compatible Receivers - VE2812R VE1812R VE811R VE814AR VE801R VE802R VE601R VE901R or future ATEN HDBaseT Receivers
  • Plug-and-play with no software installation required
  • Rack mountable

Product Details

Product TypeVideo Extender Transmitter
Graphics Modes4K UHD
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Video Resolution4096 x 2160
Twisted Pair Cable StandardCategory 6a
Maximum Operating Distance492.13 ft
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Number of HDMI Inputs1
VGA InYes
HDMI InYes
Media Type SupportedTwisted Pair
Number of Input Devices Supported2
Transmitter Height1.18"
Transmitter Width4.84"
Transmitter Depth5.64"
Transmitter Weight (Approximate)1.04 lb
Number of VGA Inputs1
Connectivity TechnologyWired
Brand NameATEN
Form FactorDesktop
ManufacturerATEN Technology Inc
Product ModelVE2812AT
Product NameHDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
Product LineVanCryst
Manufacturer Part NumberVE2812AT
Manufacturer Website Addresshttp://www.aten.com/us/en/
Marketing Information

ATEN VE2812AT is a transmitter for sending VGA (with audio) and HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring built-in PoH (Power over HDBaseT) function the VE2812AT receives power supply from the HDBaseT output port on the connected device. This eliminates the need for a power adapter and reduces the hassle of power line deployment behind the wall. The VE2812AT guarantees reliable transmission of HDMI signals supporting 3D Deep Color and embedded HD lossless audio formats. It also ensures transmission of VGA (with audio) at distance up to 100 m. In addition it supports Long Reach Mode up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p.

For utility flexibility the VE2812AT can serve as a video switch by connecting two sources and distribute them to an identical output. The VE2812AT is recommended to be deployed in paired with the VE2812R. The VE2812R can carry on IR/RS-232 from the VE2812R to the VE2812AT allowing users to remotely control the VE2812AT unit through RS-232 command mode via input port switching. The solution is ideal for a variety of settings such as meeting rooms digital educational environment or wherever high video quality is required.
Package Contents
  • HDMI & VGA HDBaseT Transmitter with POH (4K@100m) (HDBaseT Class A)
  • 1 x RS-232 Terminal Block
  • 4 x Foot Pads
  • 1 x Power Adapter
  • 1 x User Instructions
Product FamilyVanCryst
