    PS2 W/ AUDIO KVM EXTENDER
1 1

ATEN ProXime CE350 KVM Console/Extender-TAA Compliant

ATEN ProXime CE350 KVM Console/Extender-TAA Compliant

SKU: 1018143121      MFR: ATEN Technology Inc

GTIN: 672792002410

Product Description

ATEN ProXime CE350 KVM Console/Extender-TAA Compliant - 1 Computer(s) - 492.13 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution - 2 x Network (RJ-45) - 4 x PS/2 Port - 2 x VGA - Proprietary Interface - 5.3 V DC Input Voltage - Rack-mountable

Manufacturer : ATEN Technology Inc

Manufacturer Part No : CE350

Features

  • Local and Remote Units connect at distances up to 150 m using Cat 5e cable
  • Adjustable gain control - automatically and manually adjust signal strength to compensate for distance
  • Dual console operation - control your system from both the local and remote keyboard monitor and mouse consoles
  • Built-in ASIC for greater reliability and compatibility
  • Auto Signal Compensation (ASC) and storage of settings
  • RS-232 serial ports - connect to a serial terminal or serial devices such as touchscreens and barcode scanners (Baud Rate up to 115200 bps)
  • Audio Enabled - supports stereo speakers and microphone
  • Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes with the press of a single button
  • Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
  • Superior video quality - 1920 x 1200@60Hz(30 m) 1600 x 1200@60Hz(150 m)

Product Details

Product TypeKVM Console/Extender
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Video Resolution1920 x 1200
Graphic ModeWUXGA
Maximum Operating Distance492.13 ft
VGAYes
HeadphoneYes
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Proprietary InterfaceYes
PS/2 PortYes
Number of PS/2 Ports4
Number of VGA Ports2
KVM TechnologyAnalog
Number of Computers Supported1
Transmitter Weight (Approximate)1.06 lb
Receiver Weight (Approximate)1.08 lb
Country of OriginTaiwan
Connectivity TechnologyWired
Brand NameATEN
Form FactorRack-mountable
ManufacturerATEN Technology Inc
MicrophoneYes
Product ModelCE350
Product NameProXime CE350 KVM Console/Extender
Product LineProXime
Input Voltage5.3 V DC
Manufacturer Part NumberCE350
Manufacturer Website Addresshttp://www.aten.com/us/en/
Marketing Information

The CE350 a PS/2 based KVM Extender with automatic signal compensation and RS-232 serial functionality allows access to a computer system from a remote PS/2 console (PS/2 keyboard monitor and PS/2 mouse). Because it allows access to a computer system from a remote console the CE350 is perfect for use in any type of installation where you need to place the console where it is conveniently accessible but you want the system equipment to reside in a safe location - away from the dust and dirt of the factory floor or the harsh environmental influence of a construction site for example. This allows users to deploy system equipment over large distances.

More from the Manufacturer
Packaged Quantity1
Package Contents
  • ProXime CE350 KVM Console/Extender
  • 1 x Custom PS/2 KVM Cable Set (1.8 m)
  • 2 x Power Adapters
  • 1 x Rack Mount Kit
  • 2 x Grounding Wires
  • 1 x User Manual
  • 1 x Quick Start Guide
Product FamilyProXime
