• B+B SmartWorx 120W Single Output Industrial DIN RAIL With PFC Function
    B+B SmartWorx 120W Single Output Industrial DIN RAIL With PFC Function
1 1

B+B SmartWorx 120W Single Output Industrial DIN RAIL With PFC Function

B+B SmartWorx 120W Single Output Industrial DIN RAIL With PFC Function

SKU: 1069839161      MFR: Advantech Co. Ltd

Product Description

B+B SmartWorx 120W Single Output Industrial DIN RAIL With PFC Function - DIN Rail - 120 V AC 230 V AC Input - 12 V DC Output - 120 W - 89% Efficiency

Manufacturer : Advantech Co. Ltd

Manufacturer Part No : BB-SDR-120-12

Features

  • High efficiency 91% low power dissipation
  • 150% peak load capability
  • Built-in active PFC function PF>0.93
  • Protections: Short-circuit Overload Over-voltage Over-temperature
  • Free air convection cooling
  • DIN rail mountable TS-35/7.5 or 15
  • UL508 approved (industrial control equipment)
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • Built-in DC OK relay contact
  • 100% full-load burn-in test

Product Details

Product TypePower Supply
Environmentally FriendlyYes
Environmental CertificationTaiwan RoHS
Country of OriginTaiwan
Height4.9"
Width1.6"
Depth4.5"
Product SeriesSDR-120
Brand NameB+B SmartWorx
Output Current10 A
Form FactorDIN Rail
ManufacturerAdvantech Co. Ltd
Product ModelSDR-120-12
Product Name120W Single Output Industrial DIN RAIL With PFC Function
Product LineMeanWell
Efficiency89%
Input Voltage120 V AC
Input Voltage230 V AC
Manufacturer Part NumberBB-SDR-120-12
Manufacturer Website Addresshttp://www.advantech.com
Marketing Information

Model SDR-120-12 power supply is enclose in a DIN rail mountable case with touch-guard screw terminals and features universal input single output power-on LED display built-in active PFC function DC OK relay contact and peak load capability. The power supply protects against short circuit overvoltage and overload by current limiting (hiccup after 3s).
Output Power120 W
Packaged Quantity20
Limited Warranty3 Year
Output Voltage12 V DC
Product FamilyMeanWell SDR-120
View full details
$166.99 USD
$166.99
Sale Sold out

Out Of Stock


Update


Shipping calculated at checkout.

B+B SmartWorx 120W Single Output Industrial DIN RAIL With PFC Function - DIN Rail - 120 V AC 230 V AC Input - 12 V DC Output - 120 W - 89% Efficiency

Manufacturer : Advantech Co. Ltd

Manufacturer Part No : BB-SDR-120-12

Features

  • High efficiency 91% low power dissipation
  • 150% peak load capability
  • Built-in active PFC function PF>0.93
  • Protections: Short-circuit Overload Over-voltage Over-temperature
  • Free air convection cooling
  • DIN rail mountable TS-35/7.5 or 15
  • UL508 approved (industrial control equipment)
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • Built-in DC OK relay contact
  • 100% full-load burn-in test

Product Details

Product TypePower Supply
Environmentally FriendlyYes
Environmental CertificationTaiwan RoHS
Country of OriginTaiwan
Height4.9"
Width1.6"
Depth4.5"
Product SeriesSDR-120
Brand NameB+B SmartWorx
Output Current10 A
Form FactorDIN Rail
ManufacturerAdvantech Co. Ltd
Product ModelSDR-120-12
Product Name120W Single Output Industrial DIN RAIL With PFC Function
Product LineMeanWell
Efficiency89%
Input Voltage120 V AC
Input Voltage230 V AC
Manufacturer Part NumberBB-SDR-120-12
Manufacturer Website Addresshttp://www.advantech.com
Marketing Information

Model SDR-120-12 power supply is enclose in a DIN rail mountable case with touch-guard screw terminals and features universal input single output power-on LED display built-in active PFC function DC OK relay contact and peak load capability. The power supply protects against short circuit overvoltage and overload by current limiting (hiccup after 3s).
Output Power120 W
Packaged Quantity20
Limited Warranty3 Year
Output Voltage12 V DC
Product FamilyMeanWell SDR-120
