SKU: 1071205438      MFR: Advantech Co. Ltd

Product Description

B+B SmartWorx Industrial Serial to Fiber Optic Converters - 2 x ST Ports - Multi-mode - 820 nm Fiber - 2.49 Mile - Power Supply - DIN Rail Mountable

Manufacturer : Advantech Co. Ltd

Manufacturer Part No : BB-FOSTCDRI-INV

Features

  • Converts serial data signals to multi-mode ST fiber
  • 2000V 3-way optical isolation (input/output/power); EMI/RFI protection
  • Data rate: up to 115.2 kbps
  • Wide operating temperature: -40 to +80 °C
  • DIN mount IP20 plastic case
  • UL Class 1 / Division 2
  • Modbus ASCII/RTU compatible
  • 10-48 VDC power source required (not included sold separately)
  • Inverted fiber state option (Model# BB-FOSTCDRI-INV)

Product Details

Product TypeTransceiver/Media Converter
Network (RJ-45)No
Number of ST Ports2
Media Type SupportedOptical Fiber
Fiber Mode SupportedMulti-mode
Total Number of Ports2
Brand NameB+B SmartWorx
Form FactorDIN Rail Mountable
Maximum Distance Supported2.49 Mile
Power SourcePower Supply
Environmentally FriendlyYes
Environmental CertificationWEEE
Fiber Optic Cable Standard62.5/125 µm
Fiber Optic Wavelength820 nm
Height4.8"
Width4.4"
Depth1.3"
Plug/Connector TypeTerminal Block
ManufacturerAdvantech Co. Ltd
Product ModelBB-FOSTCDRI-INV
Product NameIndustrial Serial to Fiber Optic Converters
Power Consumption1.30 W
Manufacturer Part NumberBB-FOSTCDRI-INV
Manufacturer Website Addresshttp://www.advantech.com
Marketing InformationModel BB-FOSTCDRI is a premium industrial serial to multi-mode fiber optic converter. Its rugged design is UL Approved and certified for Class 1/Division 2 industrial environments. It extends data communications up to 4 km (2.5 mi). It provides three-way optical isolation on the input output and power lines.

In addition to direct point-to-point connectivity it is capable of operating in a multi-drop mode. This allows one serial device to communicate with up to 31 other devices around a fiber ring. Since it supports mixed standards you can replace other converters and isolators and add the EMI / RFI protection inherent to fiber optic communications.

In RS-232 mode the converter supports Transmit and Receive data. Handshaking signals are not passed through. An Automatic Send Data Control circuit controls the RS-422/485 driver chip eliminating the requirement for external software.

Easy to install and configure it has a 12-position DIP switch on the bottom to configure RS-422/485 parameters. Serial data and power cables connect to removable terminal blocks. ST connectors are used for the fiber.

A 10-30 VDC external power source is required (power supply not included sold separately).

Model BB-FOSTCDRI-INV features an "inverted fiber state" and is suitable for applications requiring the fiber optic transmit light to be Off in the idle state.
Weight (Approximate)7.04 oz
View full details
$363.99 USD
$363.99
Sale Sold out

In Stock - 1 (Available by Fri, Jun 12 - Wed, Jun 17)


Update


Shipping calculated at checkout.

B+B SmartWorx Industrial Serial to Fiber Optic Converters - 2 x ST Ports - Multi-mode - 820 nm Fiber - 2.49 Mile - Power Supply - DIN Rail Mountable

Manufacturer : Advantech Co. Ltd

Manufacturer Part No : BB-FOSTCDRI-INV

Features

  • Converts serial data signals to multi-mode ST fiber
  • 2000V 3-way optical isolation (input/output/power); EMI/RFI protection
  • Data rate: up to 115.2 kbps
  • Wide operating temperature: -40 to +80 °C
  • DIN mount IP20 plastic case
  • UL Class 1 / Division 2
  • Modbus ASCII/RTU compatible
  • 10-48 VDC power source required (not included sold separately)
  • Inverted fiber state option (Model# BB-FOSTCDRI-INV)

Product Details

Product TypeTransceiver/Media Converter
Network (RJ-45)No
Number of ST Ports2
Media Type SupportedOptical Fiber
Fiber Mode SupportedMulti-mode
Total Number of Ports2
Brand NameB+B SmartWorx
Form FactorDIN Rail Mountable
Maximum Distance Supported2.49 Mile
Power SourcePower Supply
Environmentally FriendlyYes
Environmental CertificationWEEE
Fiber Optic Cable Standard62.5/125 µm
Fiber Optic Wavelength820 nm
Height4.8"
Width4.4"
Depth1.3"
Plug/Connector TypeTerminal Block
ManufacturerAdvantech Co. Ltd
Product ModelBB-FOSTCDRI-INV
Product NameIndustrial Serial to Fiber Optic Converters
Power Consumption1.30 W
Manufacturer Part NumberBB-FOSTCDRI-INV
Manufacturer Website Addresshttp://www.advantech.com
Marketing InformationModel BB-FOSTCDRI is a premium industrial serial to multi-mode fiber optic converter. Its rugged design is UL Approved and certified for Class 1/Division 2 industrial environments. It extends data communications up to 4 km (2.5 mi). It provides three-way optical isolation on the input output and power lines.

In addition to direct point-to-point connectivity it is capable of operating in a multi-drop mode. This allows one serial device to communicate with up to 31 other devices around a fiber ring. Since it supports mixed standards you can replace other converters and isolators and add the EMI / RFI protection inherent to fiber optic communications.

In RS-232 mode the converter supports Transmit and Receive data. Handshaking signals are not passed through. An Automatic Send Data Control circuit controls the RS-422/485 driver chip eliminating the requirement for external software.

Easy to install and configure it has a 12-position DIP switch on the bottom to configure RS-422/485 parameters. Serial data and power cables connect to removable terminal blocks. ST connectors are used for the fiber.

A 10-30 VDC external power source is required (power supply not included sold separately).

Model BB-FOSTCDRI-INV features an "inverted fiber state" and is suitable for applications requiring the fiber optic transmit light to be Off in the idle state.
Weight (Approximate)7.04 oz
