In the MXConnect family BEC MX-100U 4G/LTE USB Modem is a low-cost lightweight and rugged LTE modem to provide LTE connectivity with host equipment. The device is also an LTE-Advanced (LTE-A) Category 6 supported with Carrier Aggregation (CA) three times faster than the first generation of LTE Category 3.

With the palm-size design and IP50 dust-protected enclosure the 100U can be easily carried around and attached or embedded with a BEC certified and compatible device for an instant cellular Internet connection. Also the 100U modem off­ers an additional LTE interface option to an existing LTE device to provide basic loading balancing WAN failover between these multiple WAN connections and carrier diversity for di­fferent data services all in a single-box solution.

• Carrier Network Certification: AT&T T-Mobile Verzion and Sprint

Product Major Applications:

• Industrial Applications
• Kiosk and Vending
• Digital Signage
• Embedded Systems
• OEM Design applications
• Smart Energy
• Remote connectivity
• Public Safety applications

• LTE FDD (Cat. 6) Data Rate: DL up to 300Mbps & UL up to 50 Mbps
• Carrier Aggregation
• Channel Bandwidth: 1.4 3 5 10 15 20 MHz
• RF Characteristics
• Transmit Power: +23dBm
• Sensitivity: -96dBm
• GPS(GNSS) Support with NMEA Protocol
• Regulatory: FCC PTCRB

• SMA Antenna Connectors
• 2 x LTE
• 1 x GPS
• 1 x 2FF MINI SIM Slot
• Operating Temperature: - 4 to 140º F (-20 to 60º C)
