Brainboxes 4 Port RS232 Ethernet to Serial Adapter
Brainboxes 4 Port RS232 Ethernet to Serial Adapter
SKU: 1021314983 MFR: Brainboxes Limited
GTIN: 837324009965
Product Description
Brainboxes 4 Port RS232 Ethernet to Serial Adapter - Wall-mountable DIN Rail Mountable - TAA Compliant
Manufacturer : Brainboxes Limited
Manufacturer Part No : ES-701
Features
- 4 Port RS-232 Ethernet to Serial Device Server
- Recommended for demanding flow control and latency applications such as CNC/DNC machine communications
- Serial Port Tunnelling allows serial cable replacement over any distance no software required
- IP-30 rated steel enclosure
- Data rate from 110 to 1000000 baud (1 MegaBaud)
- Install Virtual Com ports communicate over TCP/IP or use the Software APIs for Visual Basic C# and more
Product Details
Ethernet to Serial device server providing access to four RS232 serial port. Data transfer rates up to 1000000 baud rates (1 MegaBaud) coupled with 1Mbit/s line drivers deliver uncompromising performance. Baud rates can be standard values such as 9600 115200 230000 921600 or user definable non standard values.
Our ES range provides simple instant networked serial ports. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser. For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally. Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance no software required. You can access the device via TCP/IP sockets from any networked device like an Android tablet PC or phone. On Windows OS TCP/IP sockets are handled by the Winsock API this will differ on other OSs.
Item Backordered
This item will ship once it is in stock. TEKMENTUM cannot guarantee an in-stock date.
Update
Couldn't load pickup availability
![ES-701 4PORT DEVICE SVR RS232](http://tekmentum.com/cdn/shop/files/1021314983.jpg?v=1694725369&width=1445)
![Brainboxes 4 Port RS232 Ethernet to Serial Adapter](http://tekmentum.com/cdn/shop/files/1021314983_7796587d-d06d-40e4-af59-d9c4d850a51a.jpg?v=1698365099&width=1445)
Brainboxes 4 Port RS232 Ethernet to Serial Adapter - Wall-mountable DIN Rail Mountable - TAA Compliant
Manufacturer : Brainboxes Limited
Manufacturer Part No : ES-701
Features
- 4 Port RS-232 Ethernet to Serial Device Server
- Recommended for demanding flow control and latency applications such as CNC/DNC machine communications
- Serial Port Tunnelling allows serial cable replacement over any distance no software required
- IP-30 rated steel enclosure
- Data rate from 110 to 1000000 baud (1 MegaBaud)
- Install Virtual Com ports communicate over TCP/IP or use the Software APIs for Visual Basic C# and more
Product Details
Ethernet to Serial device server providing access to four RS232 serial port. Data transfer rates up to 1000000 baud rates (1 MegaBaud) coupled with 1Mbit/s line drivers deliver uncompromising performance. Baud rates can be standard values such as 9600 115200 230000 921600 or user definable non standard values.
Our ES range provides simple instant networked serial ports. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser. For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally. Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance no software required. You can access the device via TCP/IP sockets from any networked device like an Android tablet PC or phone. On Windows OS TCP/IP sockets are handled by the Winsock API this will differ on other OSs.
