C2G HDMI Ultra-Slim HDBaseT + RS232 And IR over Cat Extender Box Receiver - 4k 60hz

C2G HDMI Ultra-Slim HDBaseT + RS232 And IR over Cat Extender Box Receiver - 4k 60hz

SKU: 1068715969      MFR: C2G

GTIN: 757120300151

Product Description

C2G HDMI Ultra-Slim HDBaseT + RS232 And IR over Cat Extender Box Receiver - 4k 60hz - 1 Output Device - 230 ft Range - 1 x Network (RJ-45) - 1 x HDMI Out - 4K UHD - Twisted Pair - Category 7

Manufacturer : C2G

Manufacturer Part No : C2G30015

Features

  • Extend 4K at 60Hz (4:2:0) up to 130ft and 1080p at 60Hz up to 230ft with Cat 6a cable
  • Extend 4K at 60Hz (4:2:0) up to 115ft and 1080p at 60Hz up to 200ft with Cat 5e/6 cable
  • HDCP 2.2 compliant to create a secure connection between the source and display
  • Supports CEC pass-through allowing central control to all HDMI compatible devices
  • Supports bi-directional IR and RS232 pass-through
  • Bi-directional PoC one power adapter at either transmitter or receiver side can power both units
  • HDBaseT Chipset VS010 for simpler HDBaseT installations
  • Works with C2G30014 C2G30017 C2G30018 C2G30021 and C2G30022 transmitters

Product Details

Product TypeVideo Extender Receiver
Graphics Modes4K UHD
Twisted Pair Cable StandardCategory 7
Maximum Operating Distance230 ft
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Number of HDMI Outputs1
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported1
Receiver Height0.60"
Receiver Width4.30"
Receiver Depth2.50"
Receiver Weight (Approximate)6.40 oz
Country of OriginChina
ColorBlack
Connectivity TechnologyWired
Brand NameC2G
ManufacturerC2G
Product NameHDMI Ultra-Slim HDBaseT + RS232 And IR over Cat Extender Box Receiver - 4k 60hz
Manufacturer Part NumberC2G30015
Manufacturer Website Addresshttp://www.cablestogo.com
Marketing Information

The HDMI Ultra-Slim HDBaseT + RS232 And IR over Cat Extender Box Receiver - 4k 60hz allows a 4K HDMI source to be extended up to 130ft to a 4K display using a single Cat6a Ethernet cable. This is an ideal solution where HDMI video and audio need to be extended to displays in conference rooms classrooms lecture halls and many other installation needs that are far beyond the length limitations of standard HDMI cabling.

This receiver accepts HDMI signals over a single network patch cable. Extend 4K HDMI up to 115 feet and 1080p up to 230 feet using a Cat5e or Cat6 cable. For longer 4K distances extend 4K HDMI or up to 130 feet using a Cat6a cable.

This HDMI HDBaseT receiver is HDCP 2.2 compliant making sure that the connection from the source is secure. With bi-directional PoC support one power adapter at either transmitter or receiver side can power both units so no additional power adapter is required allowing for greater flexibility in installations. Advanced users can control bi-directional IR and RS232 pass through.

This HDBaseT receiver works with C2G30014 C2G30017 C2G30018 transmitters.

Note: Ensure a solid reliable connection between the 4K HDMI HDBaseT Extender and critical equipment. We suggest using HDMI Cables with gripping connectors that provide greater port retention than standard HDMI connectors.

Limited Warranty5 Year
