CyberPower OR500LCDRM1U Smart App LCD UPS Systems

CyberPower OR500LCDRM1U Smart App LCD UPS Systems

SKU: 1110628827      MFR: CyberPower Systems Inc

GTIN: 649532715015

Product Description

CyberPower OR500LCDRM1U Smart App LCD UPS Systems - 500VA/300W 120 VAC NEMA 5-15P 1U Rackmount 6 Outlets LCD PowerPanel® Business $300000 CEG 3YR Warranty

Manufacturer : CyberPower Systems Inc

Manufacturer Part No : OR500LCDRM1U

Features

  • Capacity: 500VA / 300W
  • Topology: Line Interactive
  • Waveform: Simulated Sine Wave
  • Output: 120Vac ± 10%
  • Plug type & cord: NEMA 5-15P 10 ft. cord
  • Outlet types: 6 × NEMA 5-15R
  • Communication: USB Relay SNMP
  • Management software: PowerPanel® Business
  • Remote management: Yes with optional RMCARD205
  • ENERGY STAR® certified: Yes

Product Details

Backup/Run Time (Half Load)12 Minute
Backup/Run Time (Full Load)3 Minute
Battery CharacteristicsMaintenance-free
EMI/RFI Noise FilterYes
Replaceable BatteryYes
Energy StarYes
Directly Connected Equipment Guarantee$300000Lifetime
AVRYes
Energy SavingGreenPower UPS™ Bypass Technology
USB (HID Compliant) PortYes
Maximum Operating Elevation10000 ft
Maximum Storage Elevation60"
Number of Battery & Surge Outlets4
Storage Relative Humidity0% - 95%
Storage Temperature5°F (-15°C) - 113°F (45°C)
Number of Surge-only Outlets2
Transfer Time8 ms
Typical Battery Recharge Time8 Hour
Receptacle Detail6 x NEMA 5-15R
Country of OriginPhilippines
Height1.8"
Width17.1"
Depth9.3"
ColorBlack
AlarmOn Battery
Certifications & Standards
  • FCC Class B
  • cUL 107.1
  • UL 1778
Product SeriesSmart App LCD UPS
Rack Height1U
Brand NameCyberPower
Plug/Connector TypeNEMA 5-15P
Input Voltage Range90 V AC - 140 V AC
Number of Batteries2
Serial PortYes
Maximum Operating Temperature104°F (40°C)
Battery Capacity7000 mAh
Environmental CertificationRoHS
Environmentally FriendlyYes
Receptacle TypeNEMA 5-15R
Battery Size6V
Input Frequency63 Hz
Product TypeLine-interactive UPS
Dataline ProtectionRJ-45
Form FactorRack-mountable
Status Indicators

On Unit:

  • Power On
  • Wiring Fault

LCD Panel:

  • Input Voltage
  • Output Voltage
  • Battery Capacity
  • Load Level
  • Runtime
  • On Battery
  • Overload
  • Silent Mode
Load Capacity500 VA
ManufacturerCyberPower Systems Inc
Product ModelOR500LCDRM1U
Product NameSmart App Intelligent LCD OR500LCDRM1U 500VA UPS
Overload ProtectionYes
Protection TypeDataline Surge
Surge Energy Rating1150 J
Waveform TypeSimulated Sine Wave
Application/UsageServer
Input Voltage120 V AC
Manufacturer Part NumberOR500LCDRM1U
Manufacturer Website Addresshttp://www.cyberpowersystems.com
Marketing Information

A rackmount UPS with line interactive topology the CyberPower Smart App LCD OR500LCDRM1U provides battery backup (using simulated sine wave output) and surge protection for department servers workgroup servers workstations network devices and telecom installations without active PFC power supplies. The OR500LCDRM1U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The OR500LCDRM1U comes with a three-year warranty and a $300000 Connected Equipment Guarantee.

More from the Manufacturer
Battery ChemistrySealed Lead Acid (SLA)
Package Contents
  • Smart App Intelligent LCD OR500LCDRM1U 500VA UPS
  • Rack Ears (2)
  • User Manual
  • Power Management Software
  • Warranty Card
  • Serial Cable
  • Phone Cable
  • USB Cable
Limited Warranty3 Year
Software IncludedPowerPanel® Business
Additional Information
  • Replacement Battery Cartridge Quantity: 1
  • Adjustable Voltage Range: 88 - 144 VAC
  • Circuit Breaker: 15A
  • Plug Style: Straight
  • Automatic Voltage Regulation: Single Boost
  • On Battery Frequency: 60 Hz ± 1%
  • On Battery Voltage: 120 VAC ± 10%
  • Output Power Factor: 0.6
  • Overload Protection: Internal Circuitry Limiting
  • Network Protection RJ45: 1-in / 1-Out (10/100/1000)
  • LCD: Multifunction LCD
  • Management Cable: USB Cable
  • SNMP / HTTP Remote Monitoring: Yes - with optional RMCARD205
  • Material of Construction: Metal
  • Operating Relative Humidity: 0 - 95 % (non-condensing)
  • Operating Temperature: 32 - 104 °F (0 - 40 °C)
Output Voltage120 V AC
Weight (Approximate)18 lb
Product FamilySmart App LCD UPS
Load Capacity (VA)500 VA
