Eaton Managed Rack PDU 5.76 kW max 200-240V 24A 24 Outlet Single-Phase PDU

Eaton Managed Rack PDU 5.76 kW max 200-240V 24A 24 Outlet Single-Phase PDU

SKU: 1028873420      MFR: Eaton Corporation

GTIN: 743172069184

Product Description

Eaton Managed Rack PDU 5.76 kW max 200-240V 24A 24 Outlet Single-Phase PDU - Switched - NEMA L6-30P - 20 x IEC 60320 C13 4 x IEC 60320 C19 - 230 V AC - 5760 W - Network (RJ-45) - 38U - Vertical

Manufacturer : Eaton Corporation

Manufacturer Part No : EMA107-10

Features

  • Enables on/off/reboot capabilities for a single piece of equipment with outlet-level control
  • Measures outlet-level power consumption and delivers Level 3 PUE to increase accuracy and precision of energy analysis
  • Single-phase and three-phase configurations provide solutions for SMB and networking closets blade server applications and colocation and large data centers
  • Manages entire environment remotely over the network from a single interface
  • ePDU G3 Managed provides ±1% billing grade accuracy an advanced LCD pixel display a hot-swap meter IEC grip outlets color-coded circuits and the ability to daisy chain four ePDUs to share the same network connection and IP address
  • Cisco EnergyWise Certified- Eaton's new ePDUs are Cisco EnergyWise Certified

Product Details

Receptacle TypeIEC 60320 C13
PDU TypeSwitched
Mounting OrientationVertical
Power Rating (Watt)5760 W
Product ColorBlack
Product FamilyePDU Managed
Width2.1"
Cord Length10 ft
Depth2.1"
Height66.5"
Network (RJ-45)Yes
Serial PortYes
Receptacle Detail20 x IEC 60320 C13
Plug/Connector Detail1 x NEMA L6-30P
Product TypePDU
Circuit BreakerYes
Input Voltage230 V AC
Country of OriginChina
Manufacturer Part NumberEMA107-10
Manufacturer Website Addresshttp://www.eaton.com
Output Voltage230 V AC
Product ModelEMA107-10
Rack Height38U
Brand NameEaton
Plug/Connector TypeNEMA L6-30P
Product SeriesManaged
Limited Warranty3 Year
Marketing InformationEaton ePDU G3 Managed technology provides a best-in-class design featuring billing grade accuracy monitoring at the outlet level on a local LCD pixel display or over a network connection. The high accuracy meter will measure current voltage power and energy for load balancing capacity planning efficiency monitoring and energy usage reporting. Outlet switching allows for on off or reboot of individual outlets which reduces the cost of managing remote or local IT data center environments. The robust design is UL rated to operate at 140 degrees F (60 degrees C) ambient operating temperature for containment and high temperature environments.
  • Outlet switching for on off and reboot control to reduce management costs
  • Outlet level metering to +/- 1% billing grade accuracy for customer billing or level 3 PUE calculations
  • LCD pixel display with hot-swap capability enables load balancing and local setup of key parameters such as IP address and display orientation
  • High operating temperature (140 degrees F / 60 degrees C) for containment or hot network closet environments
  • Daisy chain of IP addresses allows four devices to share one network connection to reduce network install costs by up to 75%
  • IEC outlet grip plug retention secures plugs in place using standard cables
Certifications & StandardscUL
Input Current24 A
ManufacturerEaton Corporation
Product LineePDU
Product NameePDU Managed EMA107-10 24-Outlets PDU
