4K 3D Surgical Display with High Visibility

This monitor faithfully reproduces stereoscopic images in 4K UHD resolution (3840 x 2160) at a high brightness of up to 450 cd/m² achieving both detail and depth for endoscopy and microsurgery.

Enhanced Sharpness

EIZO's proprietary image sharpening technology Smart Resolution with Sparse Coding (S.R.S.C.) allows full HD images shot by conventional endoscopy and surgical cameras to be displayed in high definition 4K resolution without lag.

View Large Images in Full HD

When inputting a 4K UHD signal you can zoom in on a specific area of the screen and display it with a resolution equal to or higher than full HD.

Sharp Color Reproduction with Wide Color Gamut

Not only does the monitor faithfully display the sRGB color gamut but it also reproduces images emulating the 4K video color standard BT.2020. This ensures vivid reds and yellow-greens captured with BT.2020-supported cameras are displayed more accurately.

HDR Compatibility

HDR (High Dynamic Range) is a range that approximates the human perception of color and light as content is shown on a display device. The monitor is equipped with the perceptual quantization (PQ) curve and hybrid log-gamma (HLG) for supporting HDR. This ensures images from HDR-supported endoscope cameras are displayed without crushing blacks and more closely resemble the human visual system.

Fully Flat Design

Operating rooms contain various medical devices that are arranged by the type of surgery being undertaken. In consideration of safety EIZO's surgical monitors adopt rounded corners. Furthermore the front is covered with a fully flat protective glass with IP45 for protection against foreign material and splashes (the whole monitor has an IP32 rating).

Cable Cover for Safety and Hygiene

With the attached cable cover cables can be stored neatly out of sight increasing safety and hygiene.

High Durability

The monitor has protective glass with a hardness of 9H making it resistant to impacts. Furthermore the monitor is equipped with optical bonding which removes the layer of air between the LCD panel and glass. This ensures foreign materials such as dust and moisture cannot damage the LCD panel.

Reduced Reflections

Reflections on the screen of LCD monitors are caused when external light hits the screen and reflects off of the protective glass and layer of air at different refractive indices. Optical bonding removes the layer of air in order to lower the difference of refractive indices. This softens the reflections on the screen and produces a clear highly visible image without affecting contrast.

Condensation Prevention

With optical bonding condensation cannot form between the LCD panel and protective glass so the monitor can be used in environments with wide temperature ranges without affecting visibility.

Lightweight Anti-Fog 3D Glasses for Clear Vision

The supplied 3D polarizing glasses do not require batteries for operation and are lightweight. This makes them perfect for long surgeries where heavy battery-operated glasses may fail or become uncomfortable. Furthermore the glasses have an anti-fog coating to maintain clear vision even when wearing a surgical mask.

Various 3D Signal Format Support

The monitor support Side by Side Line by Line Top/Bottom and SIMUL 3D signal formats.

3D-mode: 180 Degree Rotation

Regardless of the orientation of the endoscopic camera you can display the image in a direction that is easy to see.
