• Electro-Voice EVF-1122D/99 2-way Speaker - 500 W RMS - White
    Electro-Voice EVF-1122D/99 2-way Speaker - 500 W RMS - White
1 1

Electro-Voice EVF-1122D/99 2-way Speaker - 500 W RMS - White

Electro-Voice EVF-1122D/99 2-way Speaker - 500 W RMS - White

SKU: 1022693864      MFR: The Bosch Group

GTIN: 800549699778

Product Description

Electro-Voice EVF-1122D/99 2-way Speaker - 500 W RMS - White - 2000 W (PMPO) - 12" - 1.40" Titanium Tweeter - 49 Hz to 21 kHz - 8 Ohm

Manufacturer : The Bosch Group

Manufacturer Part No : EVF-1122D/99-PIW

Features

  • The 2-way speakers give smooth and precise production of sound to deliver an ultimate audio experience
  • Knock yourself out with 500 W RMS power
  • Hear every detail crisp and clear with a frequency response of 49 Hz-21 kHz
  • 8 Ohm impedance extracts maximum power so you will get more output from your speakers

Product Details

Crossover Type2-way
Minimum Frequency Response49 Hz
Maximum Frequency Response21 kHz
RMS Output Power500 W
PMPO Output Power2000 W
Woofer Diameter12"
Tweeter Driver Size1.40"
Woofer Driver Size12"
Tweeter Driver MaterialTitanium
Height30.3"
Product TypeSpeaker
Width16"
Depth16.3"
ColorWhite
Product SeriesEVF
Brand NameElectro-Voice
ManufacturerThe Bosch Group
Product ModelEVF-1122D/99
Product NameSingle 12" Two-Way 90° x 90° Full-Range Loudspeaker System
Impedance8 Ohm
Manufacturer Part NumberEVF-1122D/99-PIW
Manufacturer Website Addresshttp://www.bosch.com
Marketing InformationThe Electro-Voice EVF-1122D/99 is a high-power two-way loudspeaker system that can be used in a variety of applications where high-quality sound reinforcement is required in a compact lightweight package.

The EVF-1122D/99 utilizes the DH7N a high-output 3" titanium compression driver coupled to a Constant DirectivityTM 90° x 90° waveguide. The DVX3121A 12" woofer was developed using FEA optimization for motor suspension and electrical design to ensure very low distortion high efficiency and maximum intelligibility at high SPL. The crossover uses steep 24-dB-per-octave slopes with equalization for very smooth response in the vocal range linear off-axis
response and a protection circuit for long-term reliability.

The EVF-1122D/99's features make it ideal for many fixed-install applications. The trapezoidal enclosure is constructed of weather resistant birch and coated with EVCoat TM for maximum protection from the elements. The unique acoustic and rigging design allows for vertical and horizontal clusters to be built using any combination of loudspeakers from the entire EVF and EVH series. With seven horn patterns to choose from along with an assortment of low-frequency and subwoofer loudspeakers you have the tools to maximize flexibility of system design no matter what the application and budget. The innovative input panel provides a choice of Phoenix- style connector (included in all standard models) or the ability to add a dual NL4-type connector cover plate or gland-nut cover plate (for weatherizing applications). An externally accessible jumper selects passive or active operation. An available 70.7/100-V transformer kit may be easily mounted to the input panel for use in distributed systems. All these features give you the flexibility to address a large range of venues quickly and precisely supporting customer requirements with fewer items in inventory.
Package Contents
  • Single 12" Two-Way 90° x 90° Full-Range Loudspeaker System
  • Phoenix-Style Connector
Sensitivity97 dB
Weight (Approximate)65.50 lb
Product FamilyEVF
