GeoVision GV-APOE0810 10-Port 10/100/1000M Unmanaged PoE Switch with 8-Port PoE

GeoVision GV-APOE0810 10-Port 10/100/1000M Unmanaged PoE Switch with 8-Port PoE

SKU: 1059856662      MFR: GeoVision Inc

GTIN: 4712896448656

Product Description

GeoVision GV-APOE0810 10-Port 10/100/1000M Unmanaged PoE Switch with 8-Port PoE - 120 V AC 230 V AC Input - 2 x 10/100/1000Base-T Input Port(s) - 8 x 10/100/1000Base-T Output Port(s) - 120 W

Manufacturer : GeoVision Inc

Manufacturer Part No : 140-APOE81W-000

Features

  • PoE connection for network cables up to 250 m (820 ft) at 10 Mbps transfer rate
  • 10-port 10/100/1000BaseT(X) 8-port with Power over Ethernet
  • IEEE 802.3at Compliant (8 Ports at Full 15.4 W / 4 Ports at Full 30 W)
  • Max. 125 W power consumption
  • VLAN Mode for each PoE port to work independently
  • Up to 8 GV-IP Camera support

Product Details

Product TypePoE Injector
Brand NameGeoVision
Output Ports8 x 10/100/1000Base-T
CompatibilityGeoVision GV-IP Camera
Form FactorRack Mountable
ManufacturerGeoVision Inc
Product ModelGV-APOE0810
Product NameGV-APOE0810 10-Port 10/100/1000M Unmanaged PoE Switch with 8-Port PoE
Protection TypeSurge Protection
Input Voltage120 V AC
Input Voltage230 V AC
Manufacturer Part Number140-APOE81W-000
Manufacturer Website Addresshttp://www.geovision.com.tw
Marketing Information

GV-APOE0810 is a 10-port 10/100/1000 Mbps unmanaged PoE Switch with 8 PSE/PoE ports and 2 uplink ports. The switch supports IEEE 802.3at Power over Ethernet standard up to 32 W per port for up to 8 GV-IP devices and a maximum power consumption of 125 W. In addition to not requiring special network cables for connecting your powered devices (PD) such as IP cameras it also allows power supply over cables of up to 250 m (820 ft) in length at 10 Mbps. The switch is designed for small or medium network environment to strengthen its network connection and efficiency. It also gives you the option of VLAN mode to isolate each of the PoE ports for an enhanced forwarding rate of time.
Package Contents
  • GV-APOE0810 10-Port 10/100/1000M Unmanaged PoE Switch with 8-Port PoE
  • AC Power Cord
  • 4 x Rubber Feet
  • Rack Mount Kit
  • 8 x Screws
Limited Warranty24 Month
Additional Information
  • MAC Address: 8 K
  • Buffer Memory: 2 M bits
  • Transmission Method: Store and Forward
  • Transmission Media: 10/100BaseT(X) Cat. 5 UTP/STP 1000BaseT Cat. 5e 6 UTP/STP
  • Packet Forwarding Rate: 13.4 Mpps
  • Backplane Capacity: 20 Gbps
  • PoE Mode: Mode A Max.
  • Power Consumption: 125 W
  • Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F)
  • Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)
  • Humidity: 10 to 90% RH (non-condensing)
  • Surge Protection: ±4 kV
Weight (Approximate)2.73 lb
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Output Power120 W
Height1.7"
Width8.7"
Depth5.9"
Certifications & Standards
  • IEEE-802.3at PoE+ / PSE
  • IEEE 802.3 10BaseT
  • IEEE 802.3u 100BaseTX
  • IEEE 802.ab 1000BaseT
  • IEEE 802.3x Flow Contro
  • CE
  • FCC Class A
Input Ports2 x 10/100/1000Base-T
