• THINLINE II WIEGAND CLASSIC
    THINLINE II WIEGAND CLASSIC
1 1

HID ThinLine II 5395C Smart Card Reader

HID ThinLine II 5395C Smart Card Reader

SKU: 1013015944      MFR: HID Global Corporation

Product Description

HID ThinLine II 5395C Smart Card Reader - 5.50" Operating Range - Wiegand - White

Manufacturer : HID Global Corporation

Manufacturer Part No : 5395CW100

Features

  • Security - Recognizes card formats up to 85 bits with over 137 billion unique codes.
  • Audiovisual Indication - A red LED flashes green and the beeper sounds when reader is presented with a proximity card. The multicolor LED and beeper can also be controlled individually by the host system.
  • Diagnostics - On reader power-up an internal self-test routine checks and verifies the setup configuration determines the internal or external control of the LED and beeper and initializes reader operation. An additional external loop-back test allows for the reader outputs and inputs to be verified without the use of additional test equipment.
  • Indoor/outdoor Design - Sealed in a rugged weatherized polycarbonate enclosure designed to withstand harsh environments providing reliable performance and a high degree of vandal resistance.
  • Easily Interfaced - Wiegand output model interfaces with all existing Wiegand protocol access control systems. Clock-and-Data (magnetic stripe) model interfaces with most systems that accept magnetic stripe readers.
  • Options - LED and beeper operation

Product Details

Product TypeSmart Card Reader
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Operating Range5.50"
Height4.7"
Width3"
Depth0.7"
ColorWhite
Brand NameHID
ManufacturerHID Global Corporation
Product Model5395C
Product NameThinLine II 5395C Smart Card Reader
Product LineThinLine II
Manufacturer Part Number5395CW100
Manufacturer Website Addresshttp://www.hidcorp.com
Marketing Information

LOW PROFILE PROXIMITY CARD READER

Providing performance and reliability HID's attractive unobtrusive ThinLine® II proximity card reader is housed in a two-piece weatherproof secure potted enclosure.

  • Easily installed and maintained with the use of replaceable covers.
  • Available with a Wiegand or Clock-and-Data interface.
  • Provides high reliability consistent read range and low power consumption.
  • Features include multicolor LED and internal control or host control of the LED and beeper.
  • Mounts directly on metal with minimal impact on the read range performance.
  • Aesthetic design available in two cover designs and four colors to match any décor.
  • Includes multilingual installation manual.
Package Contents
  • ThinLine II 5395C Smart Card Reader
  • Multilingual Installation Manual
Limited WarrantyLifetime
Host InterfaceWiegand
Additional Information
  • Available with a Wiegand or Clock-and-Data interface
  • Provides high reliability consistent read range and low power consumption
  • Features include multicolor LED and internal control or host control of the LED and beeper
  • Mounts directly on metal with minimal impact on the read range performance
Weight (Approximate)7.33 oz
Product FamilyThinLine II
View full details
$572.99 USD
$572.99
Sale Sold out

Back Order

Get it by Thu, Sep 10 - Tue, Sep 15


Update


Shipping calculated at checkout.

HID ThinLine II 5395C Smart Card Reader - 5.50" Operating Range - Wiegand - White

Manufacturer : HID Global Corporation

Manufacturer Part No : 5395CW100

Features

  • Security - Recognizes card formats up to 85 bits with over 137 billion unique codes.
  • Audiovisual Indication - A red LED flashes green and the beeper sounds when reader is presented with a proximity card. The multicolor LED and beeper can also be controlled individually by the host system.
  • Diagnostics - On reader power-up an internal self-test routine checks and verifies the setup configuration determines the internal or external control of the LED and beeper and initializes reader operation. An additional external loop-back test allows for the reader outputs and inputs to be verified without the use of additional test equipment.
  • Indoor/outdoor Design - Sealed in a rugged weatherized polycarbonate enclosure designed to withstand harsh environments providing reliable performance and a high degree of vandal resistance.
  • Easily Interfaced - Wiegand output model interfaces with all existing Wiegand protocol access control systems. Clock-and-Data (magnetic stripe) model interfaces with most systems that accept magnetic stripe readers.
  • Options - LED and beeper operation

Product Details

Product TypeSmart Card Reader
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Operating Range5.50"
Height4.7"
Width3"
Depth0.7"
ColorWhite
Brand NameHID
ManufacturerHID Global Corporation
Product Model5395C
Product NameThinLine II 5395C Smart Card Reader
Product LineThinLine II
Manufacturer Part Number5395CW100
Manufacturer Website Addresshttp://www.hidcorp.com
Marketing Information

LOW PROFILE PROXIMITY CARD READER

Providing performance and reliability HID's attractive unobtrusive ThinLine® II proximity card reader is housed in a two-piece weatherproof secure potted enclosure.

  • Easily installed and maintained with the use of replaceable covers.
  • Available with a Wiegand or Clock-and-Data interface.
  • Provides high reliability consistent read range and low power consumption.
  • Features include multicolor LED and internal control or host control of the LED and beeper.
  • Mounts directly on metal with minimal impact on the read range performance.
  • Aesthetic design available in two cover designs and four colors to match any décor.
  • Includes multilingual installation manual.
Package Contents
  • ThinLine II 5395C Smart Card Reader
  • Multilingual Installation Manual
Limited WarrantyLifetime
Host InterfaceWiegand
Additional Information
  • Available with a Wiegand or Clock-and-Data interface
  • Provides high reliability consistent read range and low power consumption
  • Features include multicolor LED and internal control or host control of the LED and beeper
  • Mounts directly on metal with minimal impact on the read range performance
Weight (Approximate)7.33 oz
Product FamilyThinLine II
