KanexPro 4K HDBaseT 100 Meter HDMI Extender w/ 2-Port Ethernet Switch

KanexPro 4K HDBaseT 100 Meter HDMI Extender w/ 2-Port Ethernet Switch

SKU: 1028635699      MFR: KanexPro

GTIN: 814556016305

Product Description

KanexPro 4K HDBaseT 100 Meter HDMI Extender w/ 2-Port Ethernet Switch - 1 Input Device - 1 Output Device - 328.08 ft Range - 6 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Rack-mountable

Manufacturer : KanexPro

Manufacturer Part No : HDBASE100ME

Features

  • Extend uncompressed HDMI signals up to 330 ft. (100m) on single CAT6 cable
  • Integrates 2-Ethernet ports for network devices
  • Supports resolutions from 1080p/60@48bit
  • Supports resolutions of Ultra HD 4K@60Hz
  • Bandwidth up to 10.2 Gbps
  • HDCP CEC and EDID compliant
  • Infrared Signal Input/Output embedded over extension
  • Audio support: Dolby TrueHD & DTS Master Audio
  • Uncompressed audio support such as LPCM
  • RS-232 Control

Product Details

Product TypeVideo Extender Transmitter/Receiver
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Maximum Operating Distance328.08 ft
Number of Network (RJ-45) Ports6
Network (RJ-45)Yes
Serial PortYes
Number of HDMI Inputs1
Number of HDMI Outputs1
HDMI InYes
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported1
Number of Input Devices Supported1
Transmitter Height1.18"
Transmitter Width3.30"
Transmitter Depth5.27"
Transmitter Weight (Approximate)1.76 lb
Connectivity TechnologyWired
Brand NameKanexPro
Form FactorRack-mountable
ManufacturerKanexPro
Product Name4K HDBaseT 100 Meter HDMI Extender w/ 2-Port Ethernet Switch
Manufacturer Part NumberHDBASE100ME
Manufacturer Website Addresshttp://www.kanexpro.com
Marketing InformationThe KanexPro HDBASE100ME is a 4K compliant transmitter - receiver set that enables you to routes ultra high - definition signals up to 330 feet (100 meters) over single CAT6 cable using HDBaseT Technology. This extender also features two Ethernet ports on both the units which can be used to connect standard network devices such as 100Base-T routers switches and hubs for LAN access.

Ideally used with Apple TV's Blu-ray players game consoles satellite boxes and HDMI based computers that require extension up to 330 feet connected to an HDTV or projector. Fully compliant with HDCP EDID and DDC channels this extender supports resolutions up to ultra HD 4K 1080p/60 & 3D.

The transmitter and receiver sets are built in to metal enclosure with sturdy finish with locking HDMI connectors and power supplies which protects the unit from dis-engament or signal loss.
Package Contents
  • 1 x Transmitter
  • 1 x Receiver
Limited Warranty3 Year
View full details
$853.99 USD
$853.99
Sale Sold out

Dropship

Get it by Thu, Dec 12 - Tue, Dec 17


Update


Shipping calculated at checkout.

KanexPro 4K HDBaseT 100 Meter HDMI Extender w/ 2-Port Ethernet Switch - 1 Input Device - 1 Output Device - 328.08 ft Range - 6 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Rack-mountable

Manufacturer : KanexPro

Manufacturer Part No : HDBASE100ME

Features

  • Extend uncompressed HDMI signals up to 330 ft. (100m) on single CAT6 cable
  • Integrates 2-Ethernet ports for network devices
  • Supports resolutions from 1080p/60@48bit
  • Supports resolutions of Ultra HD 4K@60Hz
  • Bandwidth up to 10.2 Gbps
  • HDCP CEC and EDID compliant
  • Infrared Signal Input/Output embedded over extension
  • Audio support: Dolby TrueHD & DTS Master Audio
  • Uncompressed audio support such as LPCM
  • RS-232 Control

Product Details

Product TypeVideo Extender Transmitter/Receiver
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Maximum Operating Distance328.08 ft
Number of Network (RJ-45) Ports6
Network (RJ-45)Yes
Serial PortYes
Number of HDMI Inputs1
Number of HDMI Outputs1
HDMI InYes
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported1
Number of Input Devices Supported1
Transmitter Height1.18"
Transmitter Width3.30"
Transmitter Depth5.27"
Transmitter Weight (Approximate)1.76 lb
Connectivity TechnologyWired
Brand NameKanexPro
Form FactorRack-mountable
ManufacturerKanexPro
Product Name4K HDBaseT 100 Meter HDMI Extender w/ 2-Port Ethernet Switch
Manufacturer Part NumberHDBASE100ME
Manufacturer Website Addresshttp://www.kanexpro.com
Marketing InformationThe KanexPro HDBASE100ME is a 4K compliant transmitter - receiver set that enables you to routes ultra high - definition signals up to 330 feet (100 meters) over single CAT6 cable using HDBaseT Technology. This extender also features two Ethernet ports on both the units which can be used to connect standard network devices such as 100Base-T routers switches and hubs for LAN access.

Ideally used with Apple TV's Blu-ray players game consoles satellite boxes and HDMI based computers that require extension up to 330 feet connected to an HDTV or projector. Fully compliant with HDCP EDID and DDC channels this extender supports resolutions up to ultra HD 4K 1080p/60 & 3D.

The transmitter and receiver sets are built in to metal enclosure with sturdy finish with locking HDMI connectors and power supplies which protects the unit from dis-engament or signal loss.
Package Contents
  • 1 x Transmitter
  • 1 x Receiver
Limited Warranty3 Year
