• KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232
    KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232
  • KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232
1 2

KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232

KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232

SKU: 1040665781      MFR: KanexPro

GTIN: 813982021204

Product Description

KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232 - 1 Output Device - 393.70 ft Range - 1 x Network (RJ-45) - 1 x HDMI Out - Full HD - 1920 x 1080 - Twisted Pair - Category 6 - Rack-mountable

Manufacturer : KanexPro

Manufacturer Part No : EXT-AVIPH264RX

Features

  • Decode & extend pure 1080p resolutions up to 394' / 120 meters
  • Features real-time AV coding and decoding to broadcast 1080p
  • H.264 Compression technology
  • Can be used with DVI connection
  • Supports one to many many to many and point to point broadcasting
  • Dual power input: 802.3af compliant w/ POE & DC 5V
  • No power needed when connecting through a POE network switch
  • Can be cascaded to multiple extenders
  • Supports LPCM audio format
  • Smart IP Address Setting: Dynamic Host Configuration Protocol (DHCP)

Product Details

Product TypeVideo Extender Receiver
Graphics ModesFull HD
Maximum Video Resolution1920 x 1080
Twisted Pair Cable StandardCategory 6
Maximum Operating Distance393.70 ft
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Number of HDMI Outputs1
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported1
Receiver Height1.10"
Receiver Width4.69"
Receiver Depth3.13"
Receiver Weight (Approximate)9.88 oz
Connectivity TechnologyWired
Brand NameKanexPro
Form FactorRack-mountable
ManufacturerKanexPro
Product NameNetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232
Product LineNetworkAV
Manufacturer Part NumberEXT-AVIPH264RX
Manufacturer Website Addresshttp://www.kanexpro.com
Marketing Information

The KanexPro EXT-AVIPH264RX is a DHCP enabled AV over IP receiver with HDMI output to display and Ethernet. This receiver over IP uses advanced H.264 compression algorithm to transmit full HD 1080p from HDMI based displays with less bandwidth over LAN network. It supports PoE (power over Ethernet) with distances over a single CATx up to 394 ft. (120m) delivering one to one one to many and many to many over the Ethernet switch.

Applications:

Ideal for digital signage and networked AV applications where full HD 1080p can be passed over IP network delivering full audio video power data and control using a single Ethernet cable.

Please note: Power over Ethernet will be supported only with a PoE enabled network switch.

Limited Warranty3 Year
Serial PortYes
Product FamilyNetworkAV
View full details
$262.99 USD
$262.99
Sale Sold out

In Stock - 2 (Available by Sun, Dec 08 - Thu, Dec 12)


Update


Shipping calculated at checkout.

KanexPro NetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232 - 1 Output Device - 393.70 ft Range - 1 x Network (RJ-45) - 1 x HDMI Out - Full HD - 1920 x 1080 - Twisted Pair - Category 6 - Rack-mountable

Manufacturer : KanexPro

Manufacturer Part No : EXT-AVIPH264RX

Features

  • Decode & extend pure 1080p resolutions up to 394' / 120 meters
  • Features real-time AV coding and decoding to broadcast 1080p
  • H.264 Compression technology
  • Can be used with DVI connection
  • Supports one to many many to many and point to point broadcasting
  • Dual power input: 802.3af compliant w/ POE & DC 5V
  • No power needed when connecting through a POE network switch
  • Can be cascaded to multiple extenders
  • Supports LPCM audio format
  • Smart IP Address Setting: Dynamic Host Configuration Protocol (DHCP)

Product Details

Product TypeVideo Extender Receiver
Graphics ModesFull HD
Maximum Video Resolution1920 x 1080
Twisted Pair Cable StandardCategory 6
Maximum Operating Distance393.70 ft
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Number of HDMI Outputs1
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported1
Receiver Height1.10"
Receiver Width4.69"
Receiver Depth3.13"
Receiver Weight (Approximate)9.88 oz
Connectivity TechnologyWired
Brand NameKanexPro
Form FactorRack-mountable
ManufacturerKanexPro
Product NameNetworkAV H.264 HDMI Receiver over IP w/ POE & RS-232
Product LineNetworkAV
Manufacturer Part NumberEXT-AVIPH264RX
Manufacturer Website Addresshttp://www.kanexpro.com
Marketing Information

The KanexPro EXT-AVIPH264RX is a DHCP enabled AV over IP receiver with HDMI output to display and Ethernet. This receiver over IP uses advanced H.264 compression algorithm to transmit full HD 1080p from HDMI based displays with less bandwidth over LAN network. It supports PoE (power over Ethernet) with distances over a single CATx up to 394 ft. (120m) delivering one to one one to many and many to many over the Ethernet switch.

Applications:

Ideal for digital signage and networked AV applications where full HD 1080p can be passed over IP network delivering full audio video power data and control using a single Ethernet cable.

Please note: Power over Ethernet will be supported only with a PoE enabled network switch.

Limited Warranty3 Year
Serial PortYes
Product FamilyNetworkAV
