KanexPro NetworkAV H.264 HDMI Transmitter over IP w/ POE & RS-232

KanexPro NetworkAV H.264 HDMI Transmitter over IP w/ POE & RS-232

SKU: 1040665783      MFR: KanexPro

GTIN: 813982021198

Product Description

KanexPro NetworkAV H.264 HDMI Transmitter over IP w/ POE & RS-232 - 1 Input Device - 393.70 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - Full HD - 1920 x 1080 - Twisted Pair - Category 6 - Rack-mountable

Manufacturer : KanexPro

Manufacturer Part No : EXT-AVIPH264TX

Features

  • Encode and extend pure 1080p resolutions up to 394' / 120 meters
  • Features real-time AV coding and decoding to broadcast 1080p
  • H.264 Compression technology
  • Can be used with DVI connection
  • Supports one to many many to many and point to point broadcasting
  • Dual power input: 802.3af compliant w/ POE & DC 5V
  • (No need power supply when connecting with POE Switch)
  • Can be cascaded to multiple AV over IP Extenders
  • Support LPCM audio format
  • Smart IP Address Setting: Dynamic Host Configuration Protocol (DHCP)

Product Details

Product TypeVideo Extender Transmitter
Graphics ModesFull HD
Maximum Video Resolution1920 x 1080
Twisted Pair Cable StandardCategory 6
Maximum Operating Distance393.70 ft
Number of Network (RJ-45) Ports1
Network (RJ-45)Yes
Number of HDMI Inputs1
Number of HDMI Outputs1
HDMI InYes
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Input Devices Supported1
Transmitter Height1.10"
Transmitter Width4.69"
Transmitter Depth3.13"
Transmitter Weight (Approximate)9.88 oz
Connectivity TechnologyWired
Brand NameKanexPro
Form FactorRack-mountable
ManufacturerKanexPro
Product NameNetworkAV H.264 HDMI Transmitter over IP w/ POE & RS-232
Product LineNetworkAV
Manufacturer Part NumberEXT-AVIPH264TX
Manufacturer Website Addresshttp://www.kanexpro.com
Marketing Information

The KanexPro EXT-AVIPH264TX is an AV over IP transmitter with an HDMI input and Ethernet out which uses advanced H.264 compression algorithm to transmit full HD 1080p from HDMI based sources with less bandwidth over LAN network. It supports PoE (power over Ethernet) with distances over a single CATx up to 394 ft. (120m) delivering one to one one to many and many to many over the Ethernet switch.

Applications:

Ideal for digital signage and networked AV applications where full HD 1080p can be passed over IP network delivering full audio video power data and control using a single Ethernet cable.
Limited Warranty3 Year
Serial PortYes
Product FamilyNetworkAV
