SKU: 1053087068      MFR: Kramer Electronics LTD

GTIN: 7291063065560

Product Description

Kramer 4K UHD HDMI/DVI Audio & Data over HDBaseT Twisted Pair Receiver - 2 Output Device - 590.55 ft Range - 2 x Network (RJ-45) - 1 x USB - 1 x DVI Out - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 7 - Rack-mountable

Manufacturer : Kramer Electronics LTD

Manufacturer Part No : 50-80226090

Product Details

Product TypeVideo Extender Receiver
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Twisted Pair Cable StandardCategory 7
Maximum Operating Distance590.55 ft
USBYes
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Number of USB Ports1
Serial PortYes
Number of DVI Outputs1
Number of HDMI Outputs1
HDMI OutYes
DVI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported2
Receiver Height1"
Receiver Width7.38"
Receiver Depth4.53"
Receiver Weight (Approximate)1.10 lb
Country of OriginIsrael
Connectivity TechnologyWired
Brand NameKramer
Form FactorRack-mountable
ManufacturerKramer Electronics LTD
Product ModelTP-588D
Product Name4K UHD HDMI/DVI Audio & Data over HDBaseT Twisted Pair Receiver
Manufacturer Website Addresshttp://www.kramerelectronics.com
Marketing InformationThe TP-588D is a dual-output receiver with PoE support for HDBaseT TP (twisted pair) signals from a compatible Kramer HDBaseT transmitter. It decodes the HDBaseT into DVI HDMI S/PDIF balanced stereo audio and RS-232 signals. The device supports resolutions up to 4K@60Hz (4:2:0) UHD and is used in conjunction with any Kramer HDBaseT switcher or transmitter for example the WP-20 TP-580TXR or TP-780TXR.
  • Resolution Support - Up to 4K@60Hz (4:2:0) UHD and WUXGA.
  • Maximum Data Rate - Up to 10.2Gbps (3.4Gbps per channel).
  • HDTV Compatible.
  • HDCP Compliant.
  • HDMI Support - Deep Color (36bpp in normal range and 24bpp in ultra mode) 3D.
  • Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.
  • I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.
  • Lockable EDID.
  • System Range - Up to 130m (430ft) at normal mode (2K) up to 100m at normal mode (4K); up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC-HDKat6a cables.
  • Cable - Shielded twisted pair (STP) cable recommended. For optimum range and performance use use Kramer's BC-HDKat6a cable. Note that the transmission range depends on the signal resolution graphics card and display used. The distance using non-Kramer CAT 5 CAT 6 and CAT 7 cables may not reach these ranges.
  • Power over Ethernet - The receiver can operate without a dedicated power supply when connected to a device that provides PoE.
View full details
$1,331.99 USD
$1,331.99
Sale Sold out

Dropship

Get it by Thu, Dec 12 - Tue, Dec 17


Update


Shipping calculated at checkout.

Kramer 4K UHD HDMI/DVI Audio & Data over HDBaseT Twisted Pair Receiver - 2 Output Device - 590.55 ft Range - 2 x Network (RJ-45) - 1 x USB - 1 x DVI Out - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 7 - Rack-mountable

Manufacturer : Kramer Electronics LTD

Manufacturer Part No : 50-80226090

Product Details

Product TypeVideo Extender Receiver
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Twisted Pair Cable StandardCategory 7
Maximum Operating Distance590.55 ft
USBYes
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Number of USB Ports1
Serial PortYes
Number of DVI Outputs1
Number of HDMI Outputs1
HDMI OutYes
DVI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported2
Receiver Height1"
Receiver Width7.38"
Receiver Depth4.53"
Receiver Weight (Approximate)1.10 lb
Country of OriginIsrael
Connectivity TechnologyWired
Brand NameKramer
Form FactorRack-mountable
ManufacturerKramer Electronics LTD
Product ModelTP-588D
Product Name4K UHD HDMI/DVI Audio & Data over HDBaseT Twisted Pair Receiver
Manufacturer Website Addresshttp://www.kramerelectronics.com
Marketing InformationThe TP-588D is a dual-output receiver with PoE support for HDBaseT TP (twisted pair) signals from a compatible Kramer HDBaseT transmitter. It decodes the HDBaseT into DVI HDMI S/PDIF balanced stereo audio and RS-232 signals. The device supports resolutions up to 4K@60Hz (4:2:0) UHD and is used in conjunction with any Kramer HDBaseT switcher or transmitter for example the WP-20 TP-580TXR or TP-780TXR.
  • Resolution Support - Up to 4K@60Hz (4:2:0) UHD and WUXGA.
  • Maximum Data Rate - Up to 10.2Gbps (3.4Gbps per channel).
  • HDTV Compatible.
  • HDCP Compliant.
  • HDMI Support - Deep Color (36bpp in normal range and 24bpp in ultra mode) 3D.
  • Kramer Equalization & re-Klocking™ Technology - Rebuilds the digital signal to travel longer distances.
  • I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems.
  • Lockable EDID.
  • System Range - Up to 130m (430ft) at normal mode (2K) up to 100m at normal mode (4K); up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC-HDKat6a cables.
  • Cable - Shielded twisted pair (STP) cable recommended. For optimum range and performance use use Kramer's BC-HDKat6a cable. Note that the transmission range depends on the signal resolution graphics card and display used. The distance using non-Kramer CAT 5 CAT 6 and CAT 7 cables may not reach these ranges.
  • Power over Ethernet - The receiver can operate without a dedicated power supply when connected to a device that provides PoE.
