Kramer MegaTOOLS TP-780RXR Video Extender Receiver

Kramer MegaTOOLS TP-780RXR Video Extender Receiver

SKU: 1053087072      MFR: Kramer Electronics LTD

GTIN: 7291063077082

Product Description

Kramer MegaTOOLS TP-780RXR Video Extender Receiver - 1 Output Device - 330 ft Range - 2 x Network (RJ-45) - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Rack-mountable

Manufacturer : Kramer Electronics LTD

Manufacturer Part No : 50-80398190

Features

  • HDBaseT 1.0 receiver
  • Extended-reach - Up to 100m (330ft) at 4K@60Hz (4:2:0)
  • Video resolution - Up to 4K@60Hz (4:2:0) 24bpp
  • Ethernet & control signal extension
  • PoE receiver
  • Size - MegaTOOLS® - Mount 2 units side-by-side in a 1U rack space with the optional RK-T2B rack adapter.
  • Audio - E

Product Details

Product TypeVideo Extender Receiver
Graphics Modes4K
Maximum Video Resolution4096 x 2160
Maximum Operating Distance330 ft
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Serial PortYes
Number of HDMI Outputs1
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Output Devices Supported1
Receiver Height1"
Receiver Width7.38"
Receiver Depth4.53"
Receiver Weight (Approximate)1.10 lb
Connectivity TechnologyWired
Brand NameKramer
Form FactorRack-mountable
ManufacturerKramer Electronics LTD
Product ModelTP-780RXR
Product NameMegaTOOLS TP-780RXR Video Extender Receiver
Product LineMegaTOOLS
Manufacturer Part Number50-80398190
Manufacturer Website Addresshttp://www.kramerelectronics.com
Marketing Information

The TP-780Rxr is a high-performance extended-reach HDBaseT receiver for 4K@60Hz (4:2:0) HDMI Ethernet RS-232 and IR signals over twisted pair. It extends video signals to up to 100m (330ft) over CAT copper cables at up to 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions.

  • High Performance Standard Extender - Professional HDBaseT extender for providing extended-reach signals over twisted-pair copper infrastructures. TP-780Rxr is a standard extender that can be connected to any market-available HDBaseT-compliant extension product. For optimum extension reach and performance use recommended Kramer cables.
  • HDMI Signal Extension - HDMI 2.0 and HDCP 2.2 compliant. Supports deep color x.v.Color™ lip sync HDMI uncompressed audio channels Dolby TrueHD DTS-HD 2K 4K and 3D. EDID and CEC signals are passed through from the source to the display.
  • I-EDIDPro™ Kramer Intelligent EDID Processing™ - Intelligent EDID handling processing and pass-through algorithm that ensures Plug and Play operation for HDMI source and display systems.
  • Multi-channel Audio Extension - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound.
  • Ethernet Extension - Ethernet interface data flows in both directions allowing extension of up to 100Mbps Ethernet connectivity for LAN communication and device control.
  • Bidirectional RS-232 Extension - Serial interface data flows in both directions allowing data transmission and device control.
  • Bidirectional Infrared Extension - IR interface data flows in both directions allowing remote control of peripheral devices located at either end of the extended line.
  • Cost-effective Maintenance - Status LED indicators for HDMI and HDBT ports facilitate easy local maintenance and troubleshooting. Local firmware upgrade via RS-232 connection and the K-Upload tool ensures lasting field-proven deployment.
  • Easy and Elegant Installation - Single cable connectivity for both HDBaseT signals and power. Compact MegaTOOLS™ fan-less enclosure for dropped-ceiling mounting or side-by-side mounting of 2 units in a 1U rack space with the optional RK-T2B rack adapter.
Package Contents
  • MegaTOOLS TP-780RXR Video Extender Receiver
  • Power Supply 12V/2A
  • Bracket Installation Kit
Product FamilyMegaTOOLS
