Kramer MV-6 3G HD-SDI Multiviewer

Kramer MV-6 3G HD-SDI Multiviewer

SKU: 1023217459      MFR: Kramer Electronics LTD

Product Description

Kramer MV-6 3G HD-SDI Multiviewer - 1920 x 1080 - Full HD - Twisted Pair - 6 x 3 - Display - 1 x HDMI Out - 12 x SDI In - 2 x SDI Out

Manufacturer : Kramer Electronics LTD

Manufacturer Part No : MV-6

Features

  • Use this audio video switchbox and eliminate the need to manually switch cables between sources
  • Trouble free connection with display
  • Up to 1920 x 1080 video resolution

Product Details

Product TypeAudio/Video Switchbox
Graphics ModesFull HD
Maximum Video Resolution1920 x 1080
Number of HDMI Outputs1
HDMI OutYes
Media Type SupportedTwisted Pair
Number of Displays Supported3
Number of Input Devices Supported6
Connectivity (RJ-45)Yes
Number of Connectivity (RJ-45) Ports1
Number of SDI Inputs12
Number of SDI Outputs2
Country of OriginIsrael
Height3.5"
Width17.2"
Depth7.2"
Connectivity TechnologyCable
Brand NameKramer
Form FactorRack-mountable
ManufacturerKramer Electronics LTD
Product ModelMV-6
Product NameMV-6 3G HD-SDI Multiviewer
Device SupportedDisplay
Manufacturer Website Addresshttp://www.kramerelectronics.com
Marketing Information

The MV-6 is a versatile high-performance multiviewer for 3G HD-SDI video signals. The device can display up to six inputs in any combination and output the image in SDI HDMI and CV formats. Both pre-programmed and customizable screen divisions are supported. The MV-6-MD is certified for medical applications.

  • Max. Data Rate - 3Gbps.
  • HDTV Compatible.
  • Standards Compliance - Certified for medical applications according to IEC 60601-1-2 (Electromagnetic Compatibility).
  • Kramer re-Klocking™ & Equalization Technology - Rebuilds the digital signal to travel longer distances.
  • Multi-Standard Operation - SDI (SMPTE 259M) HD-SDI (SMPTE 292M) and 3G HD-SDI (SMPTE 424M).
  • Re-Clocking Looping Inputs.
  • Multi-Video Output Formats - 3G HD-SDI (SMPTE 424M) HDMI and composite scaling refresh rate and video standard conversion.
  • Front Panel Preview Screen - 16:9 4.3in color LCD displaying the output of the unit.
  • Text Overlay - A text label/icon can be added inside each window. Each label has text/background color alignment size etc settings.
  • Screen Handling Buttons - Freeze size position and 4 pre-programmed and 2 user-definable layouts.
  • Flexible Control Options - Front panel with 2-row LCD OSD Ethernet & RS-232 (supplied with PC control software).
  • Worldwide Power Supply - 100-240V AC.

APPLICATIONS

  • Professional broadcasting and production studios.
  • Presentation applications.
Weight (Approximate)6.83 lb
