12 Programmable Buttons - 3 groups; color back-lit & label capable.

Configurable Digital Volume Control Knob.

Programmable Back-Lit LCD Group Labels.

Macro Capability - Carries out multiple commands with a single press of a button.

Command Banks - Each button offers multiple layers of functions for alternate behavior toggle functionality and more.

1 USB Port - For programming.

3 Bidirectional RS-232 Ports - Control AV equipment such as projectors LCD and PDP displays power amplifiers switchers and scalers.

2 IR Outputs - Additional control port for AV equipment.

IR Learning Function - Learns commands from IR remotes.

4 Contact Closure Ports - Conveniently control other room items related to the AV system such as raising and lowering drapes the screen or the projector.

2 GPI/O Ports - General purpose I/O ports that can be configured by K-Config as digital inputs digital outputs or analog inputs for interfacing with a variety of devices such as sensors switches LEDs or relays.

2 K-NET™ Connectors - Connect to other control panels or a central control processor.

K-NET™ Control Channel - Provides power and control data to the wall plate controllers over a single cable.

Kramer Site-CTRL Compatible - For network remote control and management using Kramer Site-CTRL software over the Ethernet port.

Configured with Kramer K-Config Software.

Mud Ring Supplied for Easy Installation.

Dimensions - 16.2cm x 2.6cm x 11.4 (6.4" x 1.0" x 4.5") W D H.

Wall Plate Size - 3 gang US. Available in white black gray and brushed aluminum.
