For tile wood and laminate concrete floor coverings. For use in 6" (152mm) diameter opening. Devices are recessed 3 1/4" (83mm) below floor surface. Die-cast aluminum cover assembly is available in the following powder coated finishes: (BK) black (GY) gray (NK) nickel (BS) brass (BZ) bronze and (AL) aluminum. INCLUDED: For Side Compartments: Two (2) proprietary 20A Duplex Receptacles installed. For Center Compartment: One (1) 6ACT8A Mounting Plate One (1) 6TRAC Mounting Plate One (1) 6SER Mounting Plate. For Bottom Feed Compartment: One (1) 5BLH 1/2-Gang Blank Housing (Tunneling extends from the 5BLH to 575CHA so that power cables from the 20A duplex receptacle mounted on the left side of the poke-thru device are run into the junction box attached to the 575CHA.) One (1) 1PTHA 1-Gang Pass-Through Housing Assembly One (1) 575CHA 1/2-Gang 3/4" Conduit Housing Assembly (also includes junction box attached to the 3/4" conduit). NOTE: UL Fire Classified for up to 2-hour rated floors. Receptacles can be wired as a standard or isolated ground device. Includes one (1) 6TS Tile Shim.

• Aluminium cover assemblies: The Evolution Series poke-thru design includes all metal die-cast aluminium cover assemblies with two unique spring-loaded slide egress doors. Available in surface style and flush style in standard finishes of brass gray black nickel bronze and aluminium offering a wider range of aesthetic options.
• Meets ADA Accessibility Guidelines: Wide trim flange is designed to meet the ADA Accessibility Guidelines as it pertains to ADA Standard 4.5 which addresses changes in floor and ground surface levels. The poke-thru trim flanges are beveled so the slope is no greater than 1:2 ratio.
• UL Listed and UL Fire Classified to U.S. and Canadian safety standards: UL Fire rated for up to 2-hour rated floors maintains the fire classification of the floor.

• 2 x proprietary 20A Duplex Receptacles
• 1 x 6ACT8A Mounting Plate
• 1 x 6TRAC Mounting Plate
• 1 x 6SER Mounting Plate
• 1 x 5BLH 1/2-Gang Blank Housing
• 1 x 1PTHA 1-Gang Pass-Through Housing Assembly
• 1 x 575CHA 1/2-Gang 3/4" Conduit Housing Assembly
• 1 x 6TS Tile Shim
• Junction Box Attached to the 3/4" Conduit
