Minuteman 3000 VA On-line Tower UPS with 9 0utlets

Minuteman 3000 VA On-line Tower UPS with 9 0utlets

SKU: 1056370513      MFR: Para Systems Inc

GTIN: 784755155405

Product Description

Minuteman 3000 VA On-line Tower UPS with 9 0utlets - Tower - 3 Minute Stand-by - 120 V AC Input - 110 V AC 120 V AC 127 V AC Output - 8 x NEMA 5-15/20R 1 x NEMA L5-30R

Manufacturer : Para Systems Inc

Manufacturer Part No : EC3000LCD

Features

  • rue on-line double-conversion technology
  • Easy-to-read LCD display
  • 0.9 output power factor
  • Highly-efficient Economy Mode option
  • Output receptacle control with 2 banks
  • Extended runtime capable
  • Independent Battery Bypass - allows the UPS to provide voltage regulation and spike/surge protection either with dead batteries or without batteries
  • Hot-swappable battery replacement
  • Cold Start capable
  • Automatic internal bypass

Product Details

Product TypeDual Conversion Online UPS
Input Frequency60 Hz
Receptacle TypeNEMA 5-15/20R
Environmentally FriendlyYes
Environmental CertificationRoHS 2
Maximum Operating Temperature104°F (40°C)
Serial PortYes
Number of Batteries1
Backup/Run Time (Half Load)10 Minute
Backup/Run Time (Full Load)3 Minute
Battery CharacteristicsSealed Non-spillable Maintenance-free
EMI/RFI Noise FilterYes
Replaceable BatteryYes
EPO PortYes
USB (HID Compliant) PortYes
Maximum Operating Elevation10000 ft
Maximum Storage Elevation50000 ft
Operating Humidity10% - 90%
Storage Relative Humidity10% - 90%
Storage Temperature14°F (-10°C) - 122°F (50°C)
Transfer Time0 ns
Receptacle Detail8 x NEMA 5-15/20R
Height12.6"
Width7.6"
Depth22.4"
Output Frequency60 Hz
Brand NameMinuteman
Plug/Connector TypeNEMA L5-30P
Input Voltage Range0 V AC - 160 V AC
Dataline ProtectionRJ-45
Form FactorTower
Status Indicators
  • LCD Status Panel
  • Alarm
Load Capacity3000 VA/2700 W
ManufacturerPara Systems Inc
Product ModelEC3000LCD
Product Name3000 VA On-line Tower UPS with 9 0utlets
Network ManagementSNMP Manageable
Product LineEncompass
Surge Energy Rating254 J
Waveform TypePure Sine Wave
Application/UsageVoice/Data Network
Hot SwappableYes
Input Voltage120 V AC
Manufacturer Part NumberEC3000LCD
Manufacturer Website Addresshttp://www.minutemanups.com
Marketing InformationOn-Line UPS Comprehensive Protection

Minuteman's Encompass Series delivers the comprehensive protection only offered by a true on-line UPS. By totally regenerating the incoming AC signal through double-conversion technology an on-line UPS provides an impenetrable "electrical firewall" providing the most fail-safe power protection available.

Designed to protect the most critical equipment used in data centers voice and data communications security systems and light industrial applications. The Encompass Series is SNMP-capable (card optional) and allows full-device management using Minuteman's SentryHD™ power monitoring and control software.

The Encompass product line is a value-priced on-line UPS solution that provides an outstanding set of features true sinewave output a three-year warranty (including batteries) and is designed to meet the reliability expectations of even the most demanding critical applications. Two form factors are available in the Encompass Series: a tower-only version (EC-LCD) and a rack/tower version (EC-RT).
Sound Emission55 dB(A)
Battery ChemistryLead Acid
Package Contents
  • 3000 VA On-line Tower UPS with 9 0utlets
  • Batteries Disconnected
  • Quick Installation Guide
Limited Warranty3 Year
Software IncludedMinuteman SentryHD Power Monitoring and Control Software
Output Voltage110 V AC
Output Voltage120 V AC
Output Voltage127 V AC
Weight (Approximate)73 lb
Input Voltage Range0 V AC 160 V AC
Product FamilyEncompass
Load Capacity (VA)3000 VA
Load Capacity (W)2700 W
