• Opengear IM7232-2-DAC-LMV-AU Infrastructure Management Equipment
    Opengear IM7232-2-DAC-LMV-AU Infrastructure Management Equipment
  • Opengear IM7232-2-DAC-LMV-AU Infrastructure Management Equipment
1 2

Opengear IM7232-2-DAC-LMV-AU Infrastructure Management Equipment

Opengear IM7232-2-DAC-LMV-AU Infrastructure Management Equipment

SKU: 1070122463      MFR: Opengear

GTIN: 843295104066

Product Description

Opengear IM7232-2-DAC-LMV-AU Infrastructure Management Equipment - Remote Management Environmental Monitoring

Manufacturer : Opengear

Manufacturer Part No : IM7232-2-DAC-LMV-AU

Product Details

Product TypeInfrastructure Management Equipment
CertificationEmissions
  • FCC Part 15 Subpart B (Class A)
  • ICES-003 Issue 5 (2014)
  • AS/NZS CISPR 22: 200410 (Class A)
  • EN 55032:2015 (Class A)
  • EN 61000-3-2 Harmonics Current Emissions (2014)
  • EN 61000-3-3 Voltage Fluctuation and Flicker (2013)
Immunity
  • EN 55024 ITE Immunity (2010)
  • IEC 61000-4-2 (2008)
  • IEC 61000-4-3 (2006) A1 (2007) A2 (2010)
  • IEC 61000-4-4 (2012)
  • IEC 61000-4-5 (2014)
  • IEC 61000-4-6 (2014)
  • IEC 61000-4-8 (2010)
  • IEC 61000-4-11 (2004)
Other Agency Approvals
  • IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013 C-Tick
  • FIPS 140-2 validated module Certificate #2473 CCC
Height1.8"
Width17"
Depth10"
Product SeriesIM7200
Brand NameOpengear
Input Voltage Range100V AC to 240V AC
Form FactorRack Mount
ManufacturerOpengear
Product ModelIM7232-2-DAC-LMV-AU
Product NameIM7232-2-DAC-LMV-AU Infrastructure Management Equipment
Application/UsageRemote Management
Input Voltage120 V AC
Manufacturer Part NumberIM7232-2-DAC-LMV-AU
Manufacturer Website Addresshttp://www.opengear.com
Additional InformationInterface
  • Ethernet Ports: 2 x 10/100/1000 Ethernet/SFP Fiber port with 1500V AC Isolation and ESD Protection
  • Console Port: 1 x RJ45 RS-232 Console Port
  • Serial Ports: Software Selectable 50 to 230400 bps
  • USB: 2 x USB 3.0 console ports
  • Remote Access:
    • Integrated 4G LTE Cellular Card Integrated V.92 PSTN Dial-in Dual Ethernet aggregation & redundancy
    • Automatic Network Failover Easy browser UI IPv6
  • Console Management:
    • Built-in web terminal
    • SSH direct to consoles
    • Optional console keystroke logging
    • Alert on cable disconnects text pattern match and more
    • Inline power control
    • Multiple concurrent sessions
Memory & CPU
  • CPU: 1 GHz ARM SoC (Marvell 88F6283)
  • Memory:
    • 256 MB DDR2 SDRAM
    • 64 MB Embedded NOR Flash
  • Internal Storage 16 GB Memory
Environmental
  • Operating Temperature: 5°C to 50°C 41°F to 122°F
  • Storage Temperature: -30°C to +60°C -22°F to +140°F
  • Humidity: 5% to 90%
  • Environmental Monitoring: Serial EMD5000 to support physical smoke water leak and vibration sensors
Security Encryption & Authentication
  • SSH
  • FIPS-140-2 compliant Open SSL Module
  • Strong ciphers -AES encryption
  • Cisco-compatible IPsec
  • OpenVPN
  • AAA - TACACS+ RADIUS Active Directory/OpenLDAP Kerberos with local fallback
  • Two factor authentication via remote AAA
  • Configurable stateful firewall
  • Actively developed & support and security notifications-frequent firmware updates
Automation & Scalability
  • ZTP Lighthouse
  • RESTful API programmable and extensible
  • Auto-Response SNMP LLDP NTP
Weight (Approximate)10 lb
Product FamilyIM7200
View full details
$6,953.99 USD
$6,953.99
Sale Sold out

Dropship

Get it by Sat, Jan 04 - Thu, Jan 09


Update


Shipping calculated at checkout.

Opengear IM7232-2-DAC-LMV-AU Infrastructure Management Equipment - Remote Management Environmental Monitoring

Manufacturer : Opengear

Manufacturer Part No : IM7232-2-DAC-LMV-AU

Product Details

Product TypeInfrastructure Management Equipment
CertificationEmissions
  • FCC Part 15 Subpart B (Class A)
  • ICES-003 Issue 5 (2014)
  • AS/NZS CISPR 22: 200410 (Class A)
  • EN 55032:2015 (Class A)
  • EN 61000-3-2 Harmonics Current Emissions (2014)
  • EN 61000-3-3 Voltage Fluctuation and Flicker (2013)
Immunity
  • EN 55024 ITE Immunity (2010)
  • IEC 61000-4-2 (2008)
  • IEC 61000-4-3 (2006) A1 (2007) A2 (2010)
  • IEC 61000-4-4 (2012)
  • IEC 61000-4-5 (2014)
  • IEC 61000-4-6 (2014)
  • IEC 61000-4-8 (2010)
  • IEC 61000-4-11 (2004)
Other Agency Approvals
  • IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013 C-Tick
  • FIPS 140-2 validated module Certificate #2473 CCC
Height1.8"
Width17"
Depth10"
Product SeriesIM7200
Brand NameOpengear
Input Voltage Range100V AC to 240V AC
Form FactorRack Mount
ManufacturerOpengear
Product ModelIM7232-2-DAC-LMV-AU
Product NameIM7232-2-DAC-LMV-AU Infrastructure Management Equipment
Application/UsageRemote Management
Input Voltage120 V AC
Manufacturer Part NumberIM7232-2-DAC-LMV-AU
Manufacturer Website Addresshttp://www.opengear.com
Additional InformationInterface
  • Ethernet Ports: 2 x 10/100/1000 Ethernet/SFP Fiber port with 1500V AC Isolation and ESD Protection
  • Console Port: 1 x RJ45 RS-232 Console Port
  • Serial Ports: Software Selectable 50 to 230400 bps
  • USB: 2 x USB 3.0 console ports
  • Remote Access:
    • Integrated 4G LTE Cellular Card Integrated V.92 PSTN Dial-in Dual Ethernet aggregation & redundancy
    • Automatic Network Failover Easy browser UI IPv6
  • Console Management:
    • Built-in web terminal
    • SSH direct to consoles
    • Optional console keystroke logging
    • Alert on cable disconnects text pattern match and more
    • Inline power control
    • Multiple concurrent sessions
Memory & CPU
  • CPU: 1 GHz ARM SoC (Marvell 88F6283)
  • Memory:
    • 256 MB DDR2 SDRAM
    • 64 MB Embedded NOR Flash
  • Internal Storage 16 GB Memory
Environmental
  • Operating Temperature: 5°C to 50°C 41°F to 122°F
  • Storage Temperature: -30°C to +60°C -22°F to +140°F
  • Humidity: 5% to 90%
  • Environmental Monitoring: Serial EMD5000 to support physical smoke water leak and vibration sensors
Security Encryption & Authentication
  • SSH
  • FIPS-140-2 compliant Open SSL Module
  • Strong ciphers -AES encryption
  • Cisco-compatible IPsec
  • OpenVPN
  • AAA - TACACS+ RADIUS Active Directory/OpenLDAP Kerberos with local fallback
  • Two factor authentication via remote AAA
  • Configurable stateful firewall
  • Actively developed & support and security notifications-frequent firmware updates
Automation & Scalability
  • ZTP Lighthouse
  • RESTful API programmable and extensible
  • Auto-Response SNMP LLDP NTP
Weight (Approximate)10 lb
Product FamilyIM7200
