SIIG 4K 60Hz HDR HDMI KVM Over Cat6 Extender with S/PDIF & Touch Screen Support

SIIG 4K 60Hz HDR HDMI KVM Over Cat6 Extender with S/PDIF & Touch Screen Support

SKU: 1073986941      MFR: SIIG Inc

GTIN: 662774045252

Product Description

SIIG 4K 60Hz HDR HDMI KVM Over Cat6 Extender with S/PDIF & Touch Screen Support - Extends/splits HDMI signals up to 230ft (70m) through RJ45 network with nearly zero latency - Supports HDMI loopout - Video resolution up to 4K@60Hz 4:4::4 and HDR YUV 4:2:0 10-bit - HDCP 2.2 - Come with USB 2.0 port for keyboard/Mouse and support touch screen - S/DIF port with PCM 2ch and 5.1ch - Protection of Lightning / Surge / ESD - Plug and play - no driver required - Metal housing - 2 years warranty

Manufacturer : SIIG Inc

Manufacturer Part No : CE-H27811-S1

Features

  • Extends and transmits 4K@60Hz HDMI video/audio and USB 2.0 signals up to 230ft (70m) through a Cat6/6a/7 network cable with nearly zero latency
  • Supports USB 2.0 extension from the transmitter to the receiver allowing you to connect a keyboard/Mouse and support touch screen at the extended location for remotely operate your PC system
  • Supports digital audio extraction through the receiver's S/PDIF port with PCM 2ch Dolby DTS 5.1
  • The transmitter's HDMI loop-out allows for local monitoring of the extended display
  • The transmitter can work as an HDMI splitter with the additional HDMI output design and allows screen mirroring to another display device
  • Lightning protection surge protection ESD protection
  • Plug and play no driver installation required
  • High quality metal housing improve heat dissipation and ensure system stability during long hours of operation

Product Details

Product TypeKVM Extender
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Video Resolution3840 x 2160
Graphic Mode4K
Maximum Operating Distance229.66 ft
USBYes
HDMIYes
Number of HDMI Ports3
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Number of USB Ports3
Number of Computers Supported1
Number of Local Users Supported1
Number of Remote Users Supported1
Transmitter Height0.87"
Transmitter Width6.02"
Transmitter Depth4.15"
Receiver Height0.87"
Receiver Width6.02"
Receiver Depth4.15"
Transmitter Weight (Approximate)12.32 oz
Receiver Weight (Approximate)12.32 oz
Device TypeKVM Extender
Product ColorBlack
Country of OriginChina
Connectivity TechnologyWired
Brand NameSIIG
Input Voltage Range100-240V
Frequency50 Hz
Frequency60 Hz
ManufacturerSIIG Inc
Product Name4K 60Hz HDR HDMI KVM Over Cat6 Extender with S/PDIF & Touch Screen Support
Input Voltage120 V AC
Manufacturer Part NumberCE-H27811-S1
Manufacturer Website Addresshttp://www.siig.com
Marketing Information

Multiple Connectivity Ports
Comes with one HDMI input port one HDMI video loop-out port one HDMI video output port one USB 2.0 port (for Host) two USB 2.0 ports for keyboard & mouse or touch screen one S/PDIF (Toslink) audio output port two RJ45 network ports two reset buttons two DC power jacks (5V/2A)

Applications

  • Lecture hall
  • Educational facilities
  • Multimedia education
  • Home theater
  • Restaurant
  • Shopping center
  • Digital signage
  • Meeting room
  • Trade show
  • Library
  • Show room
  • Church
Package Contents
  • 1 x Transmitter
  • 1 x Receiver
  • 2 x Power Adapter
  • USB 2.0 Type-A to Type-A cable
  • Mounting ears & Screw kit
  • User manual
Limited Warranty2 Year
