Socket Mobile DS840 Barcode Sled Scanner

Socket Mobile DS840 Barcode Sled Scanner

SKU: 1076422470      MFR: Socket Mobile Inc

GTIN: 758497122711

Product Description

Socket Mobile DS840 Barcode Sled Scanner - Wireless Connectivity - 19.49" Scan Distance - 1D 2D - LED - Imager - Omni-directional - Bluetooth - USB - IP40 - Retail Logistics Healthcare Warehouse Hospitality Inventory Field Sales/Service Transportation

Manufacturer : Socket Mobile Inc

Manufacturer Part No : CX4090-3157

Features

  • Bluetooth Wireless Technology - Connects easily to iPhone or iPod Bluetooth devices
  • Compatibility - Certified by Apple® for iOS devices to assure compatibility. Supports HID keyboard emulation to work with any application out of the box. Socket Mobile's SDK is integrated in over 700+ applications and our scanners are one of the most natively integrated scanners available.
  • Scanning - Fast 2D 1D and omni-directional ability allowing intuitively rapid barcode scanning with highly visible and safe LED aimer
  • LED Aimer - Bright rectangular illumination field with LED dot for precise aiming
  • Scanner Feedback - Scanner provides audible scan tones hand pulsation and Bluetooth indicators
  • User Indicators - Intuitive LEDs for Bluetooth connection battery level and scanning status
  • Long Lasting Replaceable Battery - Power to last over 9 hours with field replaceable battery
  • One-Handed Operation - Insert the iPhone/iPod for a one-handed scanning solution.
  • Interchangeable Scanner - Barcode scanner can be used separately attached to a different iPhone/iPod or inserted into any model DuraSled (Case Only)
  • Interchangeable Accessories - All accessories for all DuraSleds models are the same
  • Features magnetic contacts for ease of docking
  • Application Integration - Socket Mobile's Capture SDK enables easy integration in your applications to improve business productivity with fast efficient and reliable data transfer over Bluetooth wireless technology

Product Details

Product TypeBarcode Scanner
Environmentally FriendlyYes
Environmental CertificationRoHS
Battery Capacity700 mAh
BluetoothYes
Drop Specification

Multiple drops to vinyl covered concrete at about 3 ft or 1 m
Scan PatternOmni-directional
Maximum Battery Recharge Time8 Hour
Image Sensor TypeImager
Battery Weight0.44 oz
Storage Temperature-22°F (-30°C) to 158°F (70°C)
Ingress Protection (IP) RatingIP40
RuggedYes
Scanning Capability1D
Field of View (Horizontal)42°
Field of View (Vertical)28°
Maximum Ambient Light100000 lux
Minimum Print Contrast25%
Maximum Element Resolution (Code 39)5 mil
Maximum Element Resolution (DataMatrix)20 mil
Minimum Element Resolution (PDF417)6.6 mil
Maximum Element Resolution (PDF417)10 mil
Operating Temperature32°F (0°C) to 122°F (50°C)
Image Sensor Resolution640 x 400
Humidity (Non-condensing)5% to 95%
Connectivity TechnologyWireless
Brand NameSocket Mobile
Scanning Distance19.49"
Light SourceLED
CompatibilityApple - iPhone 13/14 & iPhone 13/14 Pro
Form FactorHandheld
ManufacturerSocket Mobile Inc
Product ModelDS840
Product NameDS840 Barcode Sled Scanner
Product LineDuraSled
Application/UsageRetail
Manufacturer Part NumberCX4090-3157
Manufacturer Website Addresshttp://www.socketmobile.com
Marketing Information

Universal Barcode Scanning Sled

The DuraSled™ DS840 is a universal barcode scanning sled for 1D/2D barcodes with Bluetooth® wireless technology for Apple iPhones and iPods. The DuraSled reads printed or on-screen barcodes. It is easy-to-use and ideal for delivery services asset tracking ticketing and other application-driven mobile solutions. Its rugged case protects phones from drop damage and provides a robust versatile charging solution suitable for all workplace environments. Simply insert your iPhone/iPod pair your scanner and you are ready to go.

DuraSled supports iPhone 6 7 8 iPhone X series SE 2022 and the entire iPhone 11 and 12 series. This makes it easy for workers to mix and match DuraSled™ solutions for iPhones all while using the same accessories and application. The core components don't change when switching to a new iPhone model enabling users to maintain their mobile deployment investments for a relevant number of years.

The Capture SDK enables easy integration into native and/or web-based applications that use scanning to enhance the productivity of workers using iPhones.
Barcode Symbology Supported1D:
  • Bookland EAN
  • Chinese 2 of 5
  • Codabar
  • Code 11
  • Code 39
  • Code 93
  • Code 128
  • Composite CC-A/B
  • Composite CC-C
  • Composite TLC-39
  • Discrete 2 of 5
  • EAN-13/JAN 13
  • EAN-8/JAN 8
  • GS1 Databar
  • GS1 Databar Expanded
  • GS1 Databar Limited
  • GS1-128
  • Interleaved 2 of 5
  • Inverse 1D
  • ISBT 128
  • ISSN EAN
  • Matrix 2 of 5
  • MSI
  • UPC-A
  • UPC E/E-1
2D:

  • Aztec
  • Data Matrix
  • Han Xin
  • Maxicode
  • Micro PDF417
  • MicroQR
  • PDF417
  • QR Code
Platform SupportediOS
Battery ChemistryLithium Polymer (Li-Polymer)
Package Contents
  • DS840 Barcode Sled Scanner
  • 1 year limited Warranty on DuraSled barcode scanner
Limited Warranty1 Year
Host InterfaceUSB
Product FamilyDuraSled
View full details
$450.99 USD
$450.99
Sale Sold out

Back Order

Get it by Sun, Dec 06 - Fri, Dec 11
