StarTech.com 2-Port PCI Express Serial Card Dual Port PCIe to RS232 (DB9) Serial Card 16C1050 UART COM Retention Windows & Linux

StarTech.com 2-Port PCI Express Serial Card Dual Port PCIe to RS232 (DB9) Serial Card 16C1050 UART COM Retention Windows & Linux

SKU: 1076830186      MFR: StarTech.com

GTIN: 065030899376

Product Description

StarTech.com 2-Port PCI Express Serial Card Dual Port PCIe to RS232 (DB9) Serial Card 16C1050 UART COM Retention Windows & Linux - Connect serial RS232 (DB9) devices with this PC Serial Card. Supports 16C1050 UART - PCI Express serial card with LED activity lights - The UART PCIe supports 5/12V over pin 9 - Keep using legacy hardware with this dual serial port interface card

Manufacturer : StarTech.com

Manufacturer Part No : 21050-PC-SERIAL-LP

Features

  • PCIE TO SERIAL: Connect serial RS232 (DB9) devices to a computer with this low profile PC serial card; Features support for high performance 16C1050 UART on both DB9 male ports; Monitor activity with the built-in LED status lights on the PCI express DB9 card
  • DEVICE COMPATIBILITY: Use this serial interface card to connect barcode readers/scanners receipt printers scales PLCs medical devices etc; The UART PCIe card supplies 5V or 12V power over pin 9; Full-profile bracket included
  • APPLICATIONS: This card is ideal for IT applications such as server rooms industrial control/automation logistics and laboratories; Continue using legacy hardware with this RS232 PCIe card; DB9 ports accept screw locking serial cables
  • DUAL SERIAL PORT CARD SPECS: 16C1050 UART Max Baud 921.6 Kbps per Port 256 Byte FIFO COM Retention Supports Windows/Linux ASIX AX99100 Chipset Odd/Even/Mark/Space/None Parity Modes 5/6/7/8/9 Data Bits PCIe 2.0 x1 Low-Profile Brackets Installed
  • THE IT PRO'S CHOICE: Designed and built for IT Professionals this PCIe to RS232 card is backed for 2-years including free lifetime 24/5 multi-lingual technical assistance

Product Details

Product TypeSerial Adapter
Environmentally FriendlyYes
Environmental CertificationRoHS
Card HeightLow-profile
Number of Serial Ports (External)2
Country of OriginTaiwan
Height0.7"
Width2.6"
Depth2.6"
Brand NameStarTech.com
Form FactorPlug-in Card
ManufacturerStarTech.com
Product NameTwo-Port PCIe Serial Card
Manufacturer Part Number21050-PC-SERIAL-LP
Manufacturer Website Addresshttp://www.startech.com
Marketing Information

Add serial communication support to a Small Form Factor (SFF) or full-size system using this two-port serial card. RS-232 (DB9) support enables control and communication with serial peripheral devices.

Legacy Connectivity

Install this card to enable the continued use of legacy serial devices preventing down time and avoiding costly upgrades. The 2-port PCIe serial card is ideal for system upgrades in a wide range of applications for logistics manufacturing and freight sectors and the IT industry such as POS equipment security systems A/V installations and more.

Connect with Ease

The RS-232 card features dual ports with 16C1050 UART support 256-byte FIFO (transmit/receive) bi-directional speeds up to 921.6 Kbps per port low-profile brackets are included for SFF systems and serial port LED status lights. In addition it supports Windows and Linux systems for maximum compatibility.

21050-PC-SERIAL-LP is backed for 2-years by StarTech.com including free lifetime 24/5 multi-lingual technical assistance.
Packaged Quantity1
Platform SupportedPC
Package Contents
  • Two-Port PCIe Serial Card
  • 1 x Full Profile Bracket
  • 2 x Low Profile Bracket
  • 1 x Quick-Start Guide
Limited Warranty2 Year
Host InterfacePCI Express 2.0 x1
Weight (Approximate)5.64 oz
View full details
$71.99 USD
$71.99
Sale Sold out

In Stock - 114 (Available by Sat, Jan 04 - Wed, Jan 08)


Update


Shipping calculated at checkout.

StarTech.com 2-Port PCI Express Serial Card Dual Port PCIe to RS232 (DB9) Serial Card 16C1050 UART COM Retention Windows & Linux - Connect serial RS232 (DB9) devices with this PC Serial Card. Supports 16C1050 UART - PCI Express serial card with LED activity lights - The UART PCIe supports 5/12V over pin 9 - Keep using legacy hardware with this dual serial port interface card

Manufacturer : StarTech.com

Manufacturer Part No : 21050-PC-SERIAL-LP

Features

  • PCIE TO SERIAL: Connect serial RS232 (DB9) devices to a computer with this low profile PC serial card; Features support for high performance 16C1050 UART on both DB9 male ports; Monitor activity with the built-in LED status lights on the PCI express DB9 card
  • DEVICE COMPATIBILITY: Use this serial interface card to connect barcode readers/scanners receipt printers scales PLCs medical devices etc; The UART PCIe card supplies 5V or 12V power over pin 9; Full-profile bracket included
  • APPLICATIONS: This card is ideal for IT applications such as server rooms industrial control/automation logistics and laboratories; Continue using legacy hardware with this RS232 PCIe card; DB9 ports accept screw locking serial cables
  • DUAL SERIAL PORT CARD SPECS: 16C1050 UART Max Baud 921.6 Kbps per Port 256 Byte FIFO COM Retention Supports Windows/Linux ASIX AX99100 Chipset Odd/Even/Mark/Space/None Parity Modes 5/6/7/8/9 Data Bits PCIe 2.0 x1 Low-Profile Brackets Installed
  • THE IT PRO'S CHOICE: Designed and built for IT Professionals this PCIe to RS232 card is backed for 2-years including free lifetime 24/5 multi-lingual technical assistance

Product Details

Product TypeSerial Adapter
Environmentally FriendlyYes
Environmental CertificationRoHS
Card HeightLow-profile
Number of Serial Ports (External)2
Country of OriginTaiwan
Height0.7"
Width2.6"
Depth2.6"
Brand NameStarTech.com
Form FactorPlug-in Card
ManufacturerStarTech.com
Product NameTwo-Port PCIe Serial Card
Manufacturer Part Number21050-PC-SERIAL-LP
Manufacturer Website Addresshttp://www.startech.com
Marketing Information

Add serial communication support to a Small Form Factor (SFF) or full-size system using this two-port serial card. RS-232 (DB9) support enables control and communication with serial peripheral devices.

Legacy Connectivity

Install this card to enable the continued use of legacy serial devices preventing down time and avoiding costly upgrades. The 2-port PCIe serial card is ideal for system upgrades in a wide range of applications for logistics manufacturing and freight sectors and the IT industry such as POS equipment security systems A/V installations and more.

Connect with Ease

The RS-232 card features dual ports with 16C1050 UART support 256-byte FIFO (transmit/receive) bi-directional speeds up to 921.6 Kbps per port low-profile brackets are included for SFF systems and serial port LED status lights. In addition it supports Windows and Linux systems for maximum compatibility.

21050-PC-SERIAL-LP is backed for 2-years by StarTech.com including free lifetime 24/5 multi-lingual technical assistance.
Packaged Quantity1
Platform SupportedPC
Package Contents
  • Two-Port PCIe Serial Card
  • 1 x Full Profile Bracket
  • 2 x Low Profile Bracket
  • 1 x Quick-Start Guide
Limited Warranty2 Year
Host InterfacePCI Express 2.0 x1
Weight (Approximate)5.64 oz
