• StarTech.com 2m (6ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable Full Duplex Zipcord Fiber 100Gbps LOMMF LSZH Fiber Patch Cord
  • StarTech.com 2m (6ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable Full Duplex Zipcord Fiber 100Gbps LOMMF LSZH Fiber Patch Cord
  • StarTech.com 2m (6ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable Full Duplex Zipcord Fiber 100Gbps LOMMF LSZH Fiber Patch Cord
1 3

StarTech.com 2m (6ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable Full Duplex Zipcord Fiber 100Gbps LOMMF LSZH Fiber Patch Cord

StarTech.com 2m (6ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable Full Duplex Zipcord Fiber 100Gbps LOMMF LSZH Fiber Patch Cord

SKU: 1011209661      MFR: StarTech.com

GTIN: 65030827195

Product Description

StarTech.com 2m (6ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable Full Duplex Zipcord Fiber 100Gbps LOMMF LSZH Fiber Patch Cord - 2m (6.6ft) OM3 Multimode LC/SC-UPC Fiber Cable; 1/10/40/100 Gbps Full Duplex; 50/125µm Core w/ Aramid Sheath; Bandwidth: 2000MHz ·km at 850nm w/ VCSEL source; Outer Diameter: 2.9mm; Jacket Material: LSZH; Temp Range: -20 to 60°C (-4 to 140°F)

Manufacturer : StarTech.com

Manufacturer Part No : A50FBLCSC2

Features

  • OM3 FIBER CABLE: OM3 Laser-Optimized Multimode Fiber Cable delivers up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors for cabling servers and Storage Area Networks (SANs)
  • QUALITY CONSTRUCTION: 50/125?m fiber core/cladding is immune to EMI; Protective Aramid fiber sheath for improved tensile strength and crush resistance; LC/SC connectors with UPC polished ceramic ferrules for insertion loss below 0.3dB
  • RATINGS AND RELIABILITY: Individually tested for signal integrity; LSZH jacket emits low-smoke and fumes in case of fire; TIA/EIA compliant fiber core; Attenuation value under 2.3dB/km meets or exceeds industry standards
  • COMPATIBILITY: OM3 LC/SC multimode cable supports 1/10/40/100 Gbps for high-density network applications such as SANs data servers SFP+ and QSFP+ connections over 1000BASE-SX 10GBASE-SR 40GBASE-SR4 and 100GBASE-SR10; Backward compatible with OM2
  • SPECS: 2m (6.6ft) Color: Aqua (OM3); LC/SC UPC; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: ?2000MHz?km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm) Dynamic 2.4in (6cm); Backed for Life

Product Details

Connector Gender on First EndMale
Connector on First End Details2 x LC Network - Male
Connector on Second End Details2 x SC Network - Male
Product ColorAqua
Connector Gender on Second EndMale
Connector Type on First EndLC Network - Male
Connector Type on Second EndSC Network - Male
Core/Cladding Diameter50/125 µm
Fiber Optic ModeMulti-mode
Cable TypeFiber Optic
Cable CharacteristicPatch Cable
Cable Length6.56 ft
Device SupportedNetwork Device
Product TypeNetwork Cable
Jacket TypeLSZH
Marketing Information

Multimode 50/125 Duplex LSZH Fiber Patch Cable delivers fast reliable data transfers safely over high-end networking equipment. The 10Gb patch cable is terminated with one LC (male) connector and one SC (male) connector and is composed of 50/125 micron OM3 aqua fiber to deliver data transfers at blinding speeds making it perfect for fiber cable runs between multiple backbone switches hubs and routers. Suited for a broad range of environments this cable is housed in a flame-retardant LSZH (Low-Smoke Zero-Halogen) cable jacket ensuring minimal smoke toxicity and corrosion in the event of a fire - making it an excellent choice for a wide range of environments including industrial settings central offices and schools as well as residential settings where building codes are a consideration.

More from the Manufacturer
Limited WarrantyLifetime
Manufacturer Website Addresshttp://www.startech.com
Manufacturer Part NumberA50FBLCSC2
Country of OriginChina
Brand NameStarTech.com
Product Name10Gb Aqua Fiber Patch Cable - LC Multi-mode (M) - SC Multi-mode (M) - 2 m - Fiber Optic - 50 / 125 Micron - Aqua
ManufacturerStarTech.com
View full details
$21.99 USD
$21.99
Sale Sold out

In Stock - 397 (Available by Sun, Jun 21 - Fri, Jun 26)


Update


Shipping calculated at checkout.

StarTech.com 2m (6ft) LC/UPC to SC/UPC OM3 Multimode Fiber Optic Cable Full Duplex Zipcord Fiber 100Gbps LOMMF LSZH Fiber Patch Cord - 2m (6.6ft) OM3 Multimode LC/SC-UPC Fiber Cable; 1/10/40/100 Gbps Full Duplex; 50/125µm Core w/ Aramid Sheath; Bandwidth: 2000MHz ·km at 850nm w/ VCSEL source; Outer Diameter: 2.9mm; Jacket Material: LSZH; Temp Range: -20 to 60°C (-4 to 140°F)

Manufacturer : StarTech.com

Manufacturer Part No : A50FBLCSC2

Features

  • OM3 FIBER CABLE: OM3 Laser-Optimized Multimode Fiber Cable delivers up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors for cabling servers and Storage Area Networks (SANs)
  • QUALITY CONSTRUCTION: 50/125?m fiber core/cladding is immune to EMI; Protective Aramid fiber sheath for improved tensile strength and crush resistance; LC/SC connectors with UPC polished ceramic ferrules for insertion loss below 0.3dB
  • RATINGS AND RELIABILITY: Individually tested for signal integrity; LSZH jacket emits low-smoke and fumes in case of fire; TIA/EIA compliant fiber core; Attenuation value under 2.3dB/km meets or exceeds industry standards
  • COMPATIBILITY: OM3 LC/SC multimode cable supports 1/10/40/100 Gbps for high-density network applications such as SANs data servers SFP+ and QSFP+ connections over 1000BASE-SX 10GBASE-SR 40GBASE-SR4 and 100GBASE-SR10; Backward compatible with OM2
  • SPECS: 2m (6.6ft) Color: Aqua (OM3); LC/SC UPC; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: ?2000MHz?km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm) Dynamic 2.4in (6cm); Backed for Life

Product Details

Connector Gender on First EndMale
Connector on First End Details2 x LC Network - Male
Connector on Second End Details2 x SC Network - Male
Product ColorAqua
Connector Gender on Second EndMale
Connector Type on First EndLC Network - Male
Connector Type on Second EndSC Network - Male
Core/Cladding Diameter50/125 µm
Fiber Optic ModeMulti-mode
Cable TypeFiber Optic
Cable CharacteristicPatch Cable
Cable Length6.56 ft
Device SupportedNetwork Device
Product TypeNetwork Cable
Jacket TypeLSZH
Marketing Information

Multimode 50/125 Duplex LSZH Fiber Patch Cable delivers fast reliable data transfers safely over high-end networking equipment. The 10Gb patch cable is terminated with one LC (male) connector and one SC (male) connector and is composed of 50/125 micron OM3 aqua fiber to deliver data transfers at blinding speeds making it perfect for fiber cable runs between multiple backbone switches hubs and routers. Suited for a broad range of environments this cable is housed in a flame-retardant LSZH (Low-Smoke Zero-Halogen) cable jacket ensuring minimal smoke toxicity and corrosion in the event of a fire - making it an excellent choice for a wide range of environments including industrial settings central offices and schools as well as residential settings where building codes are a consideration.

More from the Manufacturer
Limited WarrantyLifetime
Manufacturer Website Addresshttp://www.startech.com
Manufacturer Part NumberA50FBLCSC2
Country of OriginChina
Brand NameStarTech.com
Product Name10Gb Aqua Fiber Patch Cable - LC Multi-mode (M) - SC Multi-mode (M) - 2 m - Fiber Optic - 50 / 125 Micron - Aqua
ManufacturerStarTech.com
