StarTech.com 8 Port SATA PCIe Card PCI Express 6Gbps SATA Expansion Card with 4 Controllers PCI-e x4 Gen 2 to SATA III Adapter Card

StarTech.com 8 Port SATA PCIe Card PCI Express 6Gbps SATA Expansion Card with 4 Controllers PCI-e x4 Gen 2 to SATA III Adapter Card

SKU: 1069890551      MFR: StarTech.com

GTIN: 65030893275

Product Description

StarTech.com 8 Port SATA PCIe Card PCI Express 6Gbps SATA Expansion Card with 4 Controllers PCI-e x4 Gen 2 to SATA III Adapter Card - SATA III 6Gbps PCIe x4 Gen 2 card - PCIe SATA expansion card has 2x Mini-SAS ports with Mini-SAS to 4x SATA adapter cables - 8-Port SATA PCIe Card w/ PCI Express MUX and 4 SATA controllers for max 20Gbps total - Windows/macOS/Linux - Full/low-profile

Manufacturer : StarTech.com

Manufacturer Part No : 8P6G-PCIE-SATA-CARD

Features

  • HIGH-PERFORMANCE: Add eight SATA III 6Gbps ports to your desktop computer or server using a PCIe x4 Gen 2 slot to connect SATA drives (HDD/SSD); 8-Port SATA PCIe Card features 2x Mini-SAS connections with Mini-SAS to 4x locking SATA adapter cables incl.
  • QUAD CONTROLLERS: This PCI Express SATA 6 card features a PCIe MUX and four 2-Port SATA host controllers; This architecture allows for eight total SATA (serial ATA) 6Gbps ports through a single x4 PCIe slot enabling combined total throughput up to 20Gbps
  • COMPATIBILITY: Supports PCIe Gen 2 & SATA III Specs and previous generations at lower performance (SATA I/II PCIe Gen 1); Windows (XP+) macOS (10.6.8+) Linux (2.6.32+); Improved motherboard compatibility with no bifurcation required & no built-in RAID
  • EASY INSTALL: Expansion card w/ plug-and-play setup in full or low-profile PCI-e slot (full-profile bracket installed low-profile incl); Supports storage management systems such as Storage Spaces (Microsoft) RAID Assistant (macOS) mdraid/mdadm (Linux)
  • STARTECH.COM ADVANTAGE: IT professionals choice for over 30 years; This SATA PCIe controller card converter is backed for 2-years by StarTech.com including free 24/5 North America based multi-lingual tech support

Product Details

Product TypeSATA Controller
Environmentally FriendlyYes
Environmental CertificationRoHS
Maximum Data Transfer Rate5.86 Gbit/s
RAID SupportedNo
SAS Connector Details2 SFF-8087 (36 Pin Internal Mini-SAS)
Total Number of SATA Ports8
Number of SATA Ports (Internal)8
Country of OriginChina
Height0.6"
Width2.7"
Brand NameStarTech.com
Operating System SupportedWindows XP
Form FactorPlug-in Card
Length5.9"
ManufacturerStarTech.com
Product NamePCIe SATA Card
Device SupportedServer
Controller TypeSerial ATA/600
Manufacturer Part Number8P6G-PCIE-SATA-CARD
Manufacturer Website Addresshttp://www.startech.com
Marketing Information

This 8-port SATA III (6Gbps) controller enables you to add eight SATA 6Gbps hard drives (HDDs) or solid State Drives (SSDs) to your computer system or server via an available PCIe x4 card slot. The card supports SATA III and PCI-Express Gen 2 Specifications and four SATA controllers to deliver a high-performance data storage solution.

Quad Controllers to Deliver 8-Port SATA 6Gbps Performance

Featuring four 2-Port SATA 6Gbps controllers and a PCIe-x4 MUX this SATA card enables the connection of eight high-performance SATA 6Gbps drives with a combined total throughput of up to 20Gbps. The SATA drives are connected via two Mini-SAS ports with two included Mini-SAS to 4x-SATA adapter cables. To ensure a secure connection each SATA port on the included cables features a locking connector that will prevent the drive from accidental disconnection when working inside your computer case.

Wide Compatibility

The PCIe MUX that's built into this controller card manages the downstream controllers which improves motherboard compatibility by ensuring the card will work with motherboards that support bifurcation and motherboards that do not. To further improve motherboard compatibility the card does not have a built-in RAID controller but fully supports the use of software RAID. Plus with supports for PCIe Gen 2 and SATA III Specifications this card ensures backward compatibility with previous generations (SATA I/II PCIe Gen 1) at lower performance.

The controller card is widely supported across all popular operating system platforms including Windows (XPVista7810) macOS (10.6.8 and above) and Linux (2.6.32 and above).

Hassle-Free Installation

The SATA controller card features plug-and-play installation and can be installed in full-profile and low-profile computer systems with a full-profile bracket preinstalled and an interchangeable low-profile (half-height) bracket included. The card also supports storage software data management systems such as Storage Spaces (Microsoft) RAID Assistant (MacOS) and mdraid/mdadm (Linux) for hassle-free setup partitioning and software RAID array building.

8P6G-PCIE-SATA-CARD is backed by a StarTech.com 2-year warranty and free lifetime 24/5 North American based multi-lingual support.
Packaged Quantity1
Platform SupportedPC
Package Contents
  • PCIe SATA Card
  • 1 x Full-Profile Bracket (Installed)
  • 1 x Low-Profile Bracket
  • 1 x Quick-Start Guide
  • 2 x 20 in. (50 cm) Mini-SAS to 4x SATA Cable
Limited Warranty2 Year
Host InterfacePCI Express 2.0 x4
Weight (Approximate)2.65 oz
