StarTech.com Dual-Slot M.2 to SATA Adapter - M.2 SATA Adapter for 2.5" Drive Bay - M.2 Adapter - M.2 SSD Adapter - M.2 NGFF SSD Adapter - RAID

StarTech.com Dual-Slot M.2 to SATA Adapter - M.2 SATA Adapter for 2.5" Drive Bay - M.2 Adapter - M.2 SSD Adapter - M.2 NGFF SSD Adapter - RAID

SKU: 1041804582      MFR: StarTech.com

GTIN: 065030875141

Product Description

StarTech.com Dual-Slot M.2 to SATA Adapter - M.2 SATA Adapter for 2.5" Drive Bay - M.2 Adapter - M.2 SSD Adapter - M.2 NGFF SSD Adapter - RAID - Create high-performance storage with RAID by installing two M.2 SATA SSDs into a 2.5" SATA interface - M.2 Drive to SATA Adapter - Supports B key M.2 SATA SSDs - RAID 0 1 spanning JBOD - M.2 Adapter / M.2 SSD Adapter

Manufacturer : StarTech.com

Manufacturer Part No : S322M225R

Features

  • Install two M.2 SSD drives into a single 2.5? drive bay
  • Multiple RAID modes supported: RAID 0 1 spanning or JBOD
  • Open-frame steel mounting bracket with 2.5? SATA form factor housing
  • Supports 7 mm or larger 2.5" SATA bays
  • Supports B key M.2 SATA SSDs - full-length M.2 drives (2230 2242 2260 2280)
  • Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
  • Supports SATA I II and III (up to 6Gbps)
  • TRIM support to enhance the stability and performance of your M.2 NGFF SSDs
  • SMART support
  • Easy to install with all necessary hardware included

Product Details

Product TypeDAS Storage System
Environmentally FriendlyYes
Environmental CertificationRoHS
RAID SupportedYes
Number of Total Expansion Bays2
Number of Solid State Drive Supported2
TAA CompliantYes
Country of OriginTaiwan
Height0.3"
Width2.8"
Depth3.9"
ColorRed
Brand NameStarTech.com
Form FactorInternal
ManufacturerStarTech.com
Product NameDual-Slot M.2 Drive to SATA Adapter for 2.5" Drive Bay - RAID
RAID Levels0 1 Concatenation
Controller TypeSerial ATA/600
Manufacturer Part NumberS322M225R
Manufacturer Website Addresshttp://www.startech.com
Marketing Information

Boost your system performance by enhancing the capacity speed and security of your data storage. This two-drive M.2 to SATA adapter lets you install two M.2 SATA drives instead of a SATA platter drive in a single 2.5" drive bay and increase your storage options by configuring a powerful RAID array.

Build a RAID array to enhance system performance

The dual M.2 to SATA adapter supports multiple RAID modes including RAID 0 1 or spanning helping you to achieve greater SSD capacity or data redundancy depending on your selected RAID mode. The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller so both drives can be used independently of one another.

Maximize file transfer speeds

The M.2 SATA SSD adapter lets you utilize the full potential of your SATA III controller. Using M.2 SATA SSDs in place of a platter drivereduces your data transfer bottlenecks giving you file transfer speeds of up to 6Gbps.

The M.2 NGFF SATA RAID adapter also provides TRIM support to enhance the stability and performance of your M.2 NGFF SSDs.

Easy installation

This open-frame adapter is easy to install as it comes with all the necessary installation hardware and doesn't require any extra software or drivers to get you up and running quickly.

The S322M225R is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Packaged Quantity1
Package Contents
  • Dual-Slot M.2 Drive to SATA Adapter for 2.5" Drive Bay - RAID
  • 2 x Sets of Drive-mounting Hardware
  • 4 x Adapter-mounting Screws
  • 1 x Quick-start Guide
Limited Warranty2 Year
Host InterfaceSATA/600
Weight (Approximate)1.45 oz
View full details
$54.99 USD
$54.99
Sale Sold out

In Stock - 533 (Available by Wed, Apr 16 - Mon, Apr 21)


Update


Shipping calculated at checkout.

StarTech.com Dual-Slot M.2 to SATA Adapter - M.2 SATA Adapter for 2.5" Drive Bay - M.2 Adapter - M.2 SSD Adapter - M.2 NGFF SSD Adapter - RAID - Create high-performance storage with RAID by installing two M.2 SATA SSDs into a 2.5" SATA interface - M.2 Drive to SATA Adapter - Supports B key M.2 SATA SSDs - RAID 0 1 spanning JBOD - M.2 Adapter / M.2 SSD Adapter

Manufacturer : StarTech.com

Manufacturer Part No : S322M225R

Features

  • Install two M.2 SSD drives into a single 2.5? drive bay
  • Multiple RAID modes supported: RAID 0 1 spanning or JBOD
  • Open-frame steel mounting bracket with 2.5? SATA form factor housing
  • Supports 7 mm or larger 2.5" SATA bays
  • Supports B key M.2 SATA SSDs - full-length M.2 drives (2230 2242 2260 2280)
  • Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
  • Supports SATA I II and III (up to 6Gbps)
  • TRIM support to enhance the stability and performance of your M.2 NGFF SSDs
  • SMART support
  • Easy to install with all necessary hardware included

Product Details

Product TypeDAS Storage System
Environmentally FriendlyYes
Environmental CertificationRoHS
RAID SupportedYes
Number of Total Expansion Bays2
Number of Solid State Drive Supported2
TAA CompliantYes
Country of OriginTaiwan
Height0.3"
Width2.8"
Depth3.9"
ColorRed
Brand NameStarTech.com
Form FactorInternal
ManufacturerStarTech.com
Product NameDual-Slot M.2 Drive to SATA Adapter for 2.5" Drive Bay - RAID
RAID Levels0 1 Concatenation
Controller TypeSerial ATA/600
Manufacturer Part NumberS322M225R
Manufacturer Website Addresshttp://www.startech.com
Marketing Information

Boost your system performance by enhancing the capacity speed and security of your data storage. This two-drive M.2 to SATA adapter lets you install two M.2 SATA drives instead of a SATA platter drive in a single 2.5" drive bay and increase your storage options by configuring a powerful RAID array.

Build a RAID array to enhance system performance

The dual M.2 to SATA adapter supports multiple RAID modes including RAID 0 1 or spanning helping you to achieve greater SSD capacity or data redundancy depending on your selected RAID mode. The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller so both drives can be used independently of one another.

Maximize file transfer speeds

The M.2 SATA SSD adapter lets you utilize the full potential of your SATA III controller. Using M.2 SATA SSDs in place of a platter drivereduces your data transfer bottlenecks giving you file transfer speeds of up to 6Gbps.

The M.2 NGFF SATA RAID adapter also provides TRIM support to enhance the stability and performance of your M.2 NGFF SSDs.

Easy installation

This open-frame adapter is easy to install as it comes with all the necessary installation hardware and doesn't require any extra software or drivers to get you up and running quickly.

The S322M225R is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Packaged Quantity1
Package Contents
  • Dual-Slot M.2 Drive to SATA Adapter for 2.5" Drive Bay - RAID
  • 2 x Sets of Drive-mounting Hardware
  • 4 x Adapter-mounting Screws
  • 1 x Quick-start Guide
Limited Warranty2 Year
Host InterfaceSATA/600
Weight (Approximate)1.45 oz
