StarTech.com USB to RS232/RS485/RS422 4 Port Serial Hub Adapter - Industrial Metal USB 2.0 to DB9 Serial Converter - Din Rail Mountable

StarTech.com USB to RS232/RS485/RS422 4 Port Serial Hub Adapter - Industrial Metal USB 2.0 to DB9 Serial Converter - Din Rail Mountable

SKU: 1047012361      MFR: StarTech.com

GTIN: 065030878562

Product Description

StarTech.com USB to RS232/RS485/RS422 4 Port Serial Hub Adapter - Industrial Metal USB 2.0 to DB9 Serial Converter - Din Rail Mountable - Industrial 4 port serial hub 15kV Level 4 ESD - IP30 rating metal USB to serial adapter converter w/ each DB9 port set to RS232/RS422/RS485(2wire/4wire) baud rates up to 921.6Kbps - Desk/wall/DIN rail mount - 6ft USB cable - 12V power adapter/5V USB

Manufacturer : StarTech.com

Manufacturer Part No : ICUSB234854I

Features

  • RUGGED & RELIABLE: This industrial metal USB to serial adapter hub adds 4 RS-232/422/485 ports & 1 USB 2.0 port w/ 15kV ESD surge protection (level 4) IP30 rating & locking connectors on all ports
  • 4 SERIAL PORTS: The ports on this USB to serial converter can be individually configured to RS232 RS422 or RS485 (2wire/4wire) at baud rates up to 921.6Kbps for devices like barcode scanners/printers
  • MOUNTING OPTIONS: This metal mountable 4-port serial hub w/ 6ft (1.8 m) screw-lock USB cable incl. installs securely to a desk wall or DIN rail using the built-in mounting ears & incl. DIN brackets
  • FLEXIBLE POWER: This serial hub can be powered with either the 12V screw-locking power adapter or the 5V USB input while each serial port (pin 9) can be set to 5V 12V (power adapter required) or 0V
  • WIDELY COMPATIBLE: To connect industrial grade equipment to any terminal the USB to multiple DB9 male serial converter supports current and legacy Windows Linux macOS as well as embedded platforms

Product Details

Product TypeSerial Hub
Environmentally FriendlyYes
Number of Serial Ports (External)4
TAA CompliantYes
Brand NameStarTech.com
Form FactorExternal
Host InterfaceUSB
Environmental CertificationRoHS
Country of OriginTaiwan
Height1"
Width4.6"
ManufacturerStarTech.com
Product NameUSB Serial Hub
Manufacturer Part NumberICUSB234854I
Manufacturer Website Addresshttp://www.startech.com
Marketing Information

Add four extra COM ports to your laptop or desktop computer quickly and easily. This USB to RS232/422/485 serial adapter lets you connect to your serial devices through an external USB port.

Supports multiple serial protocols

The versatile serial adapter converts a single USB port into four RS232/RS422/RS485 serial ports enabling you to connect monitor and control a wide range of serial devices such as sensors barcode scanners and LED signage. It supports four operating modes including RS232 RS422 4-wire and 2-wire RS485.

Ideal for harsh environments

With its rugged IP30-rated metal hub housing the serial adapter is built to meet the extreme demands of harsh and mission-critical environments. It provides 15 kV ESD protection which helps to reduce downtime in industrial environments where communications lines are more prone to noise emissions or sudden spikes in voltage.

The serial adapter offers flexible mounting options with a built-in wall-mounting bracket and included DIN rail mounting kit. It also features a screw-locking host connection plus a screw-locking USB-B connector on the included USB cable to prevent accidental disconnections.

Fast data transfers

The serial adapter is equipped with high-speed UARTs providing fast data rates of up to 921Kbps in RS232/422/485operating modes.

The ICUSB234854I is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Packaged Quantity1
Platform SupportedPC
Package Contents
  • USB Serial Hub
  • 1 x USBxB with Screw Lock to USBxA Cable
  • 1 x DIN Rail Kit
  • 1 x Instruction Manual
Limited Warranty2 Year
Weight (Approximate)13.50 oz
View full details
$367.99 USD
$367.99
Sale Sold out

In Stock - 418 (Available by Wed, Apr 16 - Mon, Apr 21)
