Tripp Lite Isolator Series Dual-Voltage 115/230V 1800W 60601-1 Medical-Grade Isolation Transformer C20 Inlet 8 C13 Outlets

Tripp Lite Isolator Series Dual-Voltage 115/230V 1800W 60601-1 Medical-Grade Isolation Transformer C20 Inlet 8 C13 Outlets

SKU: 1045664015      MFR: Tripp Lite by Eaton

GTIN: 37332200037

Product Description

Tripp Lite Isolator Series Dual-Voltage 115/230V 1800W 60601-1 Medical-Grade Isolation Transformer C20 Inlet 8 C13 Outlets - 1800 VA - 120 V AC 230 V AC Input - 115 V AC 230 V AC Output

Manufacturer : Tripp Lite by Eaton

Manufacturer Part No : IS1800HGDV

Features

  • Protects sensitive equipment from EMI/RFI line noise and surges
  • Cumulative leakage current less than 100 µA
  • Automatically shuts down all outlets in case of overload
  • Offers complete isolation from input AC mains power
  • Ideal for use in any industrial network or medical environment

Product Details

Product TypeIsolation Transformer
Product ColorWhite
Power Rating1800 VA
Brand NameTripp Lite
Input ReceptaclesIEC 60320 C14
Output ReceptaclesIEC 60320 C13
Input Voltage120 V AC
Environmentally FriendlyYes
Maximum Line Current15 A
Input Receptacle TypeIEC 60320 C14
Output Receptacle TypeIEC 60320 C13
Country of OriginChina
Height5.5"
Width11.8"
Depth13.8"
Form FactorCabinet
ManufacturerTripp Lite by Eaton
Product ModelIS1800HGDV
Product NameIsolator IS1800HGDV Isolation Transformer
Product LineIsolator
Manufacturer Part NumberIS1800HGDV
Manufacturer Website Addresshttps://tripplite.eaton.com/
Marketing InformationThe IS1800HGDV Isolator® Series Dual-Voltage 115/230V 1800W 50/60Hz Medical-Grade™ Transformer with full CAN/ES/IEC/EN 60601-1 listing is ideal for protecting sensitive electronic equipment in patient-care vicinities. It can be configured for either step-up voltage step-down voltage or pass-through voltage operation. Along with line isolation and continuous EMI/RFI line noise filtering its surge protection rating of 240 joules suppresses excess voltage to prevent it from damaging connected equipment.

An internal low-impedance isolation transformer component offers 100% isolation from the input mains AC line. Faraday shield reduces the cumulative leakage current of the IS1800HGDV and connected equipment to levels less than 100 microamps while removing utility switching transients and harmonics generated by other on-site loads and reducing the impact of utility or lightning related surge conditions.

Transformer filtering provides continuous common-mode noise rejection with no wearable parts. The IS1800HGDV reduces 6000V IEEE 587 Category A and B ring wave and combination wave test surges to only 0.5V common mode.

Components connect to eight C13 outlets with fuse overload protection and a lighted on/off switch. The rugged all-metal unit housing ships ready for placement in any industrial medical office network or audio/video environment. Requires a C20-to-C19 AC input cord (sold separately).
Package Contents
  • Isolator IS1800HGDV Isolation Transformer
  • 2 x Fuse Sets (115V and 230V Operation)
  • Input/Output Cable Selector Data Sheet
  • Owner's Manual
Limited Warranty2 Year
Output Voltage115 V AC
Weight (Approximate)51.21 lb
Output Receptacle Detail8 x IEC 60320 C13
Certifications & Standards
  • ANSI/AAMI ES60601-1:2005+A2+A1
  • IEC60601-1 3RD EDITION +A1
  • cAN/CSA-C22.2 NO. 60601-1:14
  • CE
  • NOM
