Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM
Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM
SKU: 1069412363 MFR: Tripp Lite by Eaton
GTIN: 37332267153
Product Description
Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM - Metered Auto Transfer Switch - NEMA 5-20P NEMA L5-20P - 16 x NEMA 5-15/20R - 120 V AC - 1U - Horizontal - Rack-mountable Wall-mountable - TAA Compliant
Manufacturer : Tripp Lite by Eaton
Manufacturer Part No : PDUMNH20AT1
Features
- Built-in Java-free HTML5-based LX Platform interface allows you 24/7 remote access
- Switches from primary to secondary power source in <7 ms to maintain constant operation
- Digital ammeter for on-site real-time load monitoring helps prevent power overloads
- Dual 12 ft. cords with NEMA L5-20P inputs connect to separate power sources
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 2-year limited warranty
Product Details
Single-Phase 20A ATS PDU Distributes and Monitors Network-Grade Power in Real Time
This monitored PDU provides real-time remote monitoring of voltage frequency and load levels via its built-in network interface. Ideal for network IT applications small computer rooms and other equipment rack applications the PDUMNH20AT1 features 16 NEMA 5-15/20R 120V outlets for connecting equipment. Dual 12-foot (3.7-meter) power cords with NEMA L5-20P inputs (two 5-20P adapters are included) connect to separate primary and secondary mains circuits backup generators UPS systems or utility power grids including out-of-phase sources.
Switches from Primary to Secondary Power Source in Milliseconds
Automatic transfer switching (ATS) allows the PDU to switch to the secondary source within 2-7 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption. An on-board ATS processor constantly evaluates the power quality of both input sources. It prevents switching if the secondary source is unavailable or of lower quality than the primary source.
Built-In LX Platform Network Management Card Allows Remote Access 24/7
The Java-free HTML5-based WEBCARDLX network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. The latest version of PowerAlert Device Manager (PADM20) provides enhanced remote management capabilities including customizable dashboard graphs to fit user preferences. The PADM20 upgrade and Tripp Lite's PowerAlert Element Manager (PAEM) form a powerful tool for expanding maintenance functions in large installations including firmware update checks and backup and restoration of device configurations.
Digital Load Meter Helps Prevent Potentially Expensive Overloads
A digital ammeter reports the total load for all connected equipment. Monitoring amperage helps ensure load levels remain well below maximum capacity with no danger of overload that could lead to costly downtime or damaged equipment. Maintaining proper load levels even while adding new equipment can keep your TCO (total cost of ownership) low.
Mounts into 1U of Rack Space or on a Wall
Use the included mounting hardware to install the all-metal housing into 1U of space in an EIA-standard 19-inch rack. You may also use the mounting brackets to secure the PDU to a wall or under a counter.
TAA-Compliant for GSA Schedule Purchases
The PDUMNH20AT1 is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
- 16-Outlets PDU
- Detachable C19 To NEMA L5-20P Secondary Input Cord 12 Ft. (3.7 m)
- 2 x L5-20R To 5-20P Plug Adapters
- Configuration Cable
- Rack-Mounting Hardware
- Cable Retention Kit
- Owner's Manual
Dropship
Update
Couldn't load pickup availability
![Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM](http://tekmentum.com/cdn/shop/files/1069412363_3272c817-3534-4901-b3b8-1833ed5b7f63.jpg?v=1698540366&width=1445)
![Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM](http://tekmentum.com/cdn/shop/files/1069412363_323ab527-06cd-4674-be52-cdc6bb6bb896.jpg?v=1698540366&width=1445)
![Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM](http://tekmentum.com/cdn/shop/files/1069412363_f437c51d-604d-401f-bd97-3a5d669b64ce.jpg?v=1698540366&width=1445)
![Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM](http://tekmentum.com/cdn/shop/files/1069412363_86b6de95-702a-4c71-95d8-79fe0748eb15.jpg?v=1698540366&width=1445)
![Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM](http://tekmentum.com/cdn/shop/files/1069412363_dc7e91ad-efcf-41e0-a57f-8d78b86ff38e.jpg?v=1698540366&width=1445)
Tripp Lite PDU ATS / Monitored 120V 1.92kW 20A 16 5-15/20R Dual L5-20P 1URM - Metered Auto Transfer Switch - NEMA 5-20P NEMA L5-20P - 16 x NEMA 5-15/20R - 120 V AC - 1U - Horizontal - Rack-mountable Wall-mountable - TAA Compliant
Manufacturer : Tripp Lite by Eaton
Manufacturer Part No : PDUMNH20AT1
Features
- Built-in Java-free HTML5-based LX Platform interface allows you 24/7 remote access
- Switches from primary to secondary power source in <7 ms to maintain constant operation
- Digital ammeter for on-site real-time load monitoring helps prevent power overloads
- Dual 12 ft. cords with NEMA L5-20P inputs connect to separate power sources
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 2-year limited warranty
Product Details
Single-Phase 20A ATS PDU Distributes and Monitors Network-Grade Power in Real Time
This monitored PDU provides real-time remote monitoring of voltage frequency and load levels via its built-in network interface. Ideal for network IT applications small computer rooms and other equipment rack applications the PDUMNH20AT1 features 16 NEMA 5-15/20R 120V outlets for connecting equipment. Dual 12-foot (3.7-meter) power cords with NEMA L5-20P inputs (two 5-20P adapters are included) connect to separate primary and secondary mains circuits backup generators UPS systems or utility power grids including out-of-phase sources.
Switches from Primary to Secondary Power Source in Milliseconds
Automatic transfer switching (ATS) allows the PDU to switch to the secondary source within 2-7 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption. An on-board ATS processor constantly evaluates the power quality of both input sources. It prevents switching if the secondary source is unavailable or of lower quality than the primary source.
Built-In LX Platform Network Management Card Allows Remote Access 24/7
The Java-free HTML5-based WEBCARDLX network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. The latest version of PowerAlert Device Manager (PADM20) provides enhanced remote management capabilities including customizable dashboard graphs to fit user preferences. The PADM20 upgrade and Tripp Lite's PowerAlert Element Manager (PAEM) form a powerful tool for expanding maintenance functions in large installations including firmware update checks and backup and restoration of device configurations.
Digital Load Meter Helps Prevent Potentially Expensive Overloads
A digital ammeter reports the total load for all connected equipment. Monitoring amperage helps ensure load levels remain well below maximum capacity with no danger of overload that could lead to costly downtime or damaged equipment. Maintaining proper load levels even while adding new equipment can keep your TCO (total cost of ownership) low.
Mounts into 1U of Rack Space or on a Wall
Use the included mounting hardware to install the all-metal housing into 1U of space in an EIA-standard 19-inch rack. You may also use the mounting brackets to secure the PDU to a wall or under a counter.
TAA-Compliant for GSA Schedule Purchases
The PDUMNH20AT1 is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
- 16-Outlets PDU
- Detachable C19 To NEMA L5-20P Secondary Input Cord 12 Ft. (3.7 m)
- 2 x L5-20R To 5-20P Plug Adapters
- Configuration Cable
- Rack-Mounting Hardware
- Cable Retention Kit
- Owner's Manual
