Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM
Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM
SKU: 1020434293 MFR: Tripp Lite by Eaton
GTIN: 37332157287
Product Description
Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM - 24 x NEMA 5-15/20R 1 x NEMA L5-30R - 2UHorizontal Rackmount Wall Mountable
Manufacturer : Tripp Lite by Eaton
Manufacturer Part No : PDUMH30AT
Features
- Single phase 30A 120V Auto Transfer Switch / ATS PDU; Highly reliable Solid State Switching
- Enables redundant A/B power option for single-corded network devices
- Separate primary & secondary inputs connect to any two compatible power sources
- 2U horizontal rackmount; 2 L5-30P inputs; 24 5-15/20R & 1 L5-30R outlets
- Digital meter reports voltage kW load level and output amperage in 4 load segments
- TAA Compliant
Product Details
- Metered PDUMH30AT 25-Outlets PDU
- Installable Plug-retention Shelves
- Rackmount Installation Brackets
- Cable Ties
PDUMH30AT Metered ATS / Auto-Transfer Switch offers 120V 30A dual-input power distribution and visual current metering in a 2U horizontal rackmount installation format. Set of two NEMA L5-30P line cords enable separate primary and secondary input connections. Includes 25 built-in outputs (24 NEMA 5-15/20R and 1 L5-30R). Digital current metering with push-button display control tracks output power consumption in 4 segments: Bank 1 (12 upper 5-15/20R outlets) Bank 2 (12 lower 5-15/20R outlets) L5-30R (single outlet) and total PDU output. Supports 2U installation in 2 or 4 post racks with additional support for wall-mount and under-counter placement.
Dropship
Update
Couldn't load pickup availability
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_90e8a743-bc8b-41a0-a4a3-0fa7645d7d45.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_1e6acceb-2aae-4551-9af0-aa9006702d13.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_0e9a7f35-0a13-403b-a9d6-32e514c4bfed.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_ca108d83-9664-4631-9b7e-c29f8e0dd2dc.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_03abd9cf-267f-4459-bde1-d4ed95915f50.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_91b1d46d-e661-47f4-8ad5-95d898717344.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_e78682de-dc4f-4c2b-a70c-d2efa7f70cca.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_344dac5b-b234-4a9d-bccb-0fc117a9fced.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_5461a0c6-3bda-48d2-946c-dffc64ebbd0b.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_337d78f8-f953-4fc5-88d5-7683ed61d846.jpg?v=1698364309&width=1445)
![Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM](http://tekmentum.com/cdn/shop/files/1020434293_49b01eeb-c224-4f2a-87d1-7bdd7b47caa8.jpg?v=1698364309&width=1445)
Tripp Lite PDU Metered ATS 120V 30A 24 5-15/20R; 1 L5-30R 2 L5-30P 2URM - 24 x NEMA 5-15/20R 1 x NEMA L5-30R - 2UHorizontal Rackmount Wall Mountable
Manufacturer : Tripp Lite by Eaton
Manufacturer Part No : PDUMH30AT
Features
- Single phase 30A 120V Auto Transfer Switch / ATS PDU; Highly reliable Solid State Switching
- Enables redundant A/B power option for single-corded network devices
- Separate primary & secondary inputs connect to any two compatible power sources
- 2U horizontal rackmount; 2 L5-30P inputs; 24 5-15/20R & 1 L5-30R outlets
- Digital meter reports voltage kW load level and output amperage in 4 load segments
- TAA Compliant
Product Details
- Metered PDUMH30AT 25-Outlets PDU
- Installable Plug-retention Shelves
- Rackmount Installation Brackets
- Cable Ties
PDUMH30AT Metered ATS / Auto-Transfer Switch offers 120V 30A dual-input power distribution and visual current metering in a 2U horizontal rackmount installation format. Set of two NEMA L5-30P line cords enable separate primary and secondary input connections. Includes 25 built-in outputs (24 NEMA 5-15/20R and 1 L5-30R). Digital current metering with push-button display control tracks output power consumption in 4 segments: Bank 1 (12 upper 5-15/20R outlets) Bank 2 (12 lower 5-15/20R outlets) L5-30R (single outlet) and total PDU output. Supports 2U installation in 2 or 4 post racks with additional support for wall-mount and under-counter placement.
