• Tycon Power POE 5 Port Switch
    Tycon Power POE 5 Port Switch
1 1

Tycon Power POE 5 Port Switch

Tycon Power POE 5 Port Switch

SKU: 1025046567      MFR: Tycon Power Systems

GTIN: 633090397608

Product Description

Tycon Power POE 5 Port Switch - 5 Ports - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - PoE - Twisted Pair - PoE Ports - Rail-mountable - 2 Year Limited Warranty

Manufacturer : Tycon Power Systems

Manufacturer Part No : TP-SW5G-24

Features

  • Create your own LAN and connect your PC laptop printer and other peripherals with the help of 5 ports
  • Cascade to other network devices through the uplink port to expand your local area network
  • Electrical power is transmitted along with data in a single cable to devices such as Access Points IP cameras or IP phones
  • Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
  • Gigabit Ethernet port for ultra-fast network speeds
  • With leading Layer 2 support experience enhanced convenience secure business operations and a borderless network experience
  • No need for power lines and outlets the switch is capable of obtaining power from the PoE source
  • Rail mounting is ideal for factory areas in vehicles and marine applications

Product Details

Marketing InformationThe SW5 Series Power Over Ethernet (POE) switches offered by Tycon Power Systems are fully automatic high speed 5 port Ethernet switches with up to 2A of POE power per port. The switch comes in 4 models:
TP-SW5G-D: IEEE802.3af/at Compliant 48VDC 10/100/1000MB POE Switch. Switch accepts 48VDC power via a wire terminal connector on the back of the Switch or via 48VDC POE into the 802.3af/at compliant uplink port (90W max). 35W per port.
TP-SW5G-24: IEEE802.3af/at Compliant 48VDC 10/100/1000MB POE Switch. Switch accepts 12-36VDC power via a wire terminal connector on the back of the Switch or via 48VDC POE into the 802.3af/at compliant uplink port (90W max). Perfect for remote solar/battery systems. 35W per port.
TP-SW5G-NC: Universal Voltage 10/100/1000MB POE Switch. Switch accepts universal voltage (12-57VDC) via the wire terminal connector on the back of the switch. Also accepts 12-57VDC (1A max) Passive POE input on port 5. 1A per port.
TP-SSW5-NC: Universal Voltage 10/100 POE Switch. Switch accepts universal voltage (12-57VDC) via the wire terminal connector on the back of the Switch. This model is very compact at only 4"x5"x1.5". 2A per port.
Power SourcePoE
Package Contents
  • POE 5 Port Switch
  • DIN Rail mounts
Limited Warranty2 Year
Layer Supported2
Weight (Approximate)13.51 oz
Product TypeEthernet Switch
Environmentally FriendlyYes
Environmental CertificationRoHS
Ethernet TechnologyGigabit Ethernet
ModularNo
Uplink PortYes
Media Type SupportedTwisted Pair
Total Number of Network Ports5
PoE (RJ-45) PortYes
Port/Expansion Slot Details4 x Gigabit Ethernet Network
Height1.6"
Width4.6"
Depth6.3"
Product SeriesTP-SW5
Brand NameTycon Power
Form FactorRail-mountable
ManufacturerTycon Power Systems
Product ModelTP-SW5G-24
Product NamePOE 5 Port Switch
Network Technology10/100/1000Base-T
Input Voltage24 V DC
Manufacturer Part NumberTP-SW5G-24
Manufacturer Website Addresshttp://www.tyconpower.com
Twisted Pair Cable StandardCategory 5
Token Ring PortNo
LRE PortNo
USBNo
Management PortNo
Number of PoE (RJ-45) Ports5
BypassNo
Certifications & Standards
  • IEEE 802.3
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3u
  • IEEE 802.3x
  • CE
  • FCC
  • UL
  • CB
Product FamilyTP-SW5
View full details
$303.99 USD
$303.99
Sale Sold out

Back Order

Get it by Tue, Aug 04 - Sun, Aug 09


Update


Shipping calculated at checkout.

Tycon Power POE 5 Port Switch - 5 Ports - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - PoE - Twisted Pair - PoE Ports - Rail-mountable - 2 Year Limited Warranty

Manufacturer : Tycon Power Systems

Manufacturer Part No : TP-SW5G-24

Features

  • Create your own LAN and connect your PC laptop printer and other peripherals with the help of 5 ports
  • Cascade to other network devices through the uplink port to expand your local area network
  • Electrical power is transmitted along with data in a single cable to devices such as Access Points IP cameras or IP phones
  • Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
  • Gigabit Ethernet port for ultra-fast network speeds
  • With leading Layer 2 support experience enhanced convenience secure business operations and a borderless network experience
  • No need for power lines and outlets the switch is capable of obtaining power from the PoE source
  • Rail mounting is ideal for factory areas in vehicles and marine applications

Product Details

Marketing InformationThe SW5 Series Power Over Ethernet (POE) switches offered by Tycon Power Systems are fully automatic high speed 5 port Ethernet switches with up to 2A of POE power per port. The switch comes in 4 models:
TP-SW5G-D: IEEE802.3af/at Compliant 48VDC 10/100/1000MB POE Switch. Switch accepts 48VDC power via a wire terminal connector on the back of the Switch or via 48VDC POE into the 802.3af/at compliant uplink port (90W max). 35W per port.
TP-SW5G-24: IEEE802.3af/at Compliant 48VDC 10/100/1000MB POE Switch. Switch accepts 12-36VDC power via a wire terminal connector on the back of the Switch or via 48VDC POE into the 802.3af/at compliant uplink port (90W max). Perfect for remote solar/battery systems. 35W per port.
TP-SW5G-NC: Universal Voltage 10/100/1000MB POE Switch. Switch accepts universal voltage (12-57VDC) via the wire terminal connector on the back of the switch. Also accepts 12-57VDC (1A max) Passive POE input on port 5. 1A per port.
TP-SSW5-NC: Universal Voltage 10/100 POE Switch. Switch accepts universal voltage (12-57VDC) via the wire terminal connector on the back of the Switch. This model is very compact at only 4"x5"x1.5". 2A per port.
Power SourcePoE
Package Contents
  • POE 5 Port Switch
  • DIN Rail mounts
Limited Warranty2 Year
Layer Supported2
Weight (Approximate)13.51 oz
Product TypeEthernet Switch
Environmentally FriendlyYes
Environmental CertificationRoHS
Ethernet TechnologyGigabit Ethernet
ModularNo
Uplink PortYes
Media Type SupportedTwisted Pair
Total Number of Network Ports5
PoE (RJ-45) PortYes
Port/Expansion Slot Details4 x Gigabit Ethernet Network
Height1.6"
Width4.6"
Depth6.3"
Product SeriesTP-SW5
Brand NameTycon Power
Form FactorRail-mountable
ManufacturerTycon Power Systems
Product ModelTP-SW5G-24
Product NamePOE 5 Port Switch
Network Technology10/100/1000Base-T
Input Voltage24 V DC
Manufacturer Part NumberTP-SW5G-24
Manufacturer Website Addresshttp://www.tyconpower.com
Twisted Pair Cable StandardCategory 5
Token Ring PortNo
LRE PortNo
USBNo
Management PortNo
Number of PoE (RJ-45) Ports5
BypassNo
Certifications & Standards
  • IEEE 802.3
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3u
  • IEEE 802.3x
  • CE
  • FCC
  • UL
  • CB
Product FamilyTP-SW5
